HD74LV1G14A
REJ03D0067-0700 Rev.7.00, Mar 21, 2008
Page 5 of 7
Switching Characteristics
•
V
CC
= 1.8 ± 0.15 V
Ta = 25°C Ta = –40 to 85°C
Item Symbol
Min Typ Max Min Max
Unit
Test
Conditions
FROM
(Input)
TO
(Output)
— 16.8 32.0 1.0 34.0 C
L
= 15 pF Propagation
delay time t
PLH
t
PHL
— 23.8 43.0 1.0 46.0
ns
C
L
= 50 pF
A
Y
•
V
CC
= 2.5 ± 0.2 V
Ta = 25°C Ta = –40 to 85°C
Item Symbol
Min Typ Max Min Max
Unit
Test
Conditions
FROM
(Input)
TO
(Output)
— 10.5 19.7 1.0 22.0 C
L
= 15 pF Propagation
delay time t
PLH
t
PHL — 14.0 24.0 1.0 27.0
ns
C
L
= 50 pF
A
Y
•
V
CC
= 3.3 ± 0.3 V
Ta = 25°C Ta = –40 to 85°C
Item Symbol
Min Typ Max Min Max
Unit
Test
Conditions
FROM
(Input)
TO
(Output)
— 8.3 12.8 1.0 15.0 C
L
= 15 pF Propagation
delay time t
PLH
t
PHL
— 10.8 16.3 1.0 18.5
ns
C
L
= 50 pF
A
Y
•
V
CC
= 5.0 ± 0.5 V
Ta = 25°C Ta = –40 to 85°C
Item Symbol
Min Typ Max Min Max
Unit
Test
Conditions
FROM
(Input)
TO
(Output)
— 5.5 8.6 1.0 10.0 C
L
= 15 pF Propagation
delay time t
PLH
t
PHL — 7.0 10.6 1.0 12.0
ns
C
L
= 50 pF
A
Y
Operating Characteristics
•
C
L
= 50 pF
V
CC
(V) Ta = 25°C
Item Symbol
Min Typ Max
Unit Test Conditions
3.3 — 8.5 — Power dissipation
capacitance
C
PD
5.0 — 10.0 —
pF f = 10 MHz
