Quick Installation Guide
Wireless PCI Adapter RNX-N300
4
5. Carefully insert the PCI adapter into the PCI port. Windows will then detect and install
the new hardware.
6.
An R icon will then appear in the system tray. Right click on the R icon and then click on
Launch Config Utilities.
Note: Click on Use Zero Configuration as Configuration Utility if you would like to use
Windows Zero Config.
PCI Adapter Adding a Profile – Windows 2000/XP/Vista
The Profile tab is used to store the settings of multiple Access Points such as home,
office, café, etc. When adding a profile you are required to enter a profile name and
SSID as well as configure the power-saving mode, network type, RTS/fragmentation
threshold and encryption/authentication settings.
1.
Profile: Enter a name for the profile; this does not need to be the same as the SSID.
2.
SSID: Enter the SSID of the network or select one from the drop-down list.
3. Network Type: Select Infrastructure from the drop-down list.
4. TX Power: Select a transmit power from the drop-down list..
5. Click on the Apply button to save the changes.
For advanced configuration, refer to the User’s Manual in the CD-ROM provided.
