SPECIFICATIONS
MODEL STAMPEDE
STRATA 5
TYPE Closed box loading Closed box loading
ROLL OFF 16Hz to 99Hz 16Hz to 99Hz
IN ROOM RESPONSE -3dB 18Hz -3dB 18Hz
INPUT CONNECTORS Neutrik Speakon – High
Level
Phono - LFE Neutrik Speakon – High Level
Phono - LFE
GAIN CONTROL RANGE 80dB 80dB
AMPLIFIER TYPE DC Coupled Mosfet
Microprocessor Controlled DC Coupled Mosfet
Microprocessor Controlled
Digital readout for all functions
Electronic lock for manual encoder to prevent accidental changes
INPUT IMPEDANCE
HIGH LEVEL TWO
CHANNEL
UNBALANCED 100K Ohms 100K Ohms
LOW LEVEL (LFE)
UNBALANCED 10K Ohms 10K Ohms
INPUT SENSITIVITY
LOW LEVEL 50mV 50mV
HIGH LEVEL 500mV 500mV
SLAM AND DEPTH -9dB to +9dB at 80Hz -9dB to +9dB at 80Hz
DRIVE UNIT 8” Heavy Duty Long Throw 10” Heavy Duty Long Throw
POWER OUTPUT
WATTS 100 Watts RMS 150 Watts RMS
PHASE 0 and 180 Degrees 0 and 180 Degrees
MAINS INPUT VOLTS
(COUNTRY SPECIFIC) 110 Volts or 230 Volts
Depending on country 110 Volts or 230 Volts
Depending on country
PROTECTION Set – Safe for driver
protection Set – Safe for driver protection
MAINS FUSES 2 Amp semi delay for
230Volts
4 Amp semi delay for 110
Volts 2 Amp semi delay for 230Volts
4 Amp semi delay for 110 Volts
DIMENSIONS WxHxD
INC. FEET AND
COINTROL 280 x 400 x 290 324 x 464 x 334
NETT WEIGHT KGS 13.4 23.2
GROSS WEIGHT KGS 15.4 26.1
SUPPLIED ACCSESSORIES
MAINS LEAD Yes Yes
NEUTRIK SPEAKON
INTERCONNECT
(HIGH LEVEL) Yes Yes
PHONO TO PHONO
INTERCONNECT (LFE) Yes Yes
SPIKES Yes Yes
USER MANUAL Yes Yes
REMOTE CONTROL
(WITH BATTERIES) Yes Yes
