6
Specifications
Input
Output
DC output power distribution
• Maximum output: 700 Watts
• Combined 3.3 V and 5 V: 170 Watts
• Maximum combined current for the +12V1, +12V2, +12V3, and +12V4 is
41 A.
• Dimensions:
• 5.5 Ч 3.4 Ч 5.9 inches (W × H × L)
• 150 Ч 86 Ч 140 mm (W × H × L)
Voltage USA, Japan, and others: 115 Vac
Europe, South East Asia, and others: 230 Vac
Frequency 60 Hz-50 Hz
Current 10 A (max.) at 115 Vac/60 Hz
7 A (max.) at 230 Vac/50 Hz
Parameter Minimum Nominal Maximum Units
Vin (115 VAC) 90 115 132 VRMS
Vin (230 VAC) 180 230 264 VRMS
Vin frequency 47 --- 63 Hz
Voltage Range Min. Nom. Max. Ripple Noise
+12 V1 ±5% +11.4 +12.00 +12.60 120 mV 200 mV
+12 V2 ±5% +11.4 +12.00 +12.60 120 mV 200 mV
+12 V3 ±5% +11.4 +12.00 +12.60 120 mV 200 mV
+12 V4 ±5% +11.4 +12.00 +12.60 120 mV 200 mV
+5 V ±5% +4.75 +5.00 +5.25 50 mV 100 mV
+3.3 V ±5% +3.14 +3.30 +3.47 50 mV 100 mV
-12 V ±10% -10.80 -10.80 -13.20 120 mV 200 mV
+5 Vsb ±5% +4.75 +4.75 +5.25 50 mV 100 mV
