Surface Mount Tweeter (Method #1)
• Use when mounting tweeter to a solid surface (metal, wood, etc.)
Mounting
Baffle
Mounting
Screw
Surface
Mount
Baseplate
Surface
Mount
Cup
Exploded View
Front View
(twist clockwise to lock)
Mounting
Baffle
Mounting
Bolt
Surface
Mount
Baseplate
Surface
Mount
Cup
Nut
Exploded View
Front View
(twist clockwise to lock)
• Use when mounting tweeter to a surface needing reinforcement
Surface Mount Tweeter (Method #2)
