AG2300
Fig.1 AUGER DRIVE SHAFT GROUP
Key# Part Number Description Q'ty
1 3890-11101 CASE(A)COMP 1
2 3890-11112 • CASE(A) 1
3 3890-11140 • PIN 2
4 3890-11201 CASE(B)COMP 1
5 06030-06001 BEARING 1
6 06031-06001 BEARING 1
7 06030-06202 BEARING 1
8 06034-06202 BEARING 1
9 3127-13230 SPACER 1
10 04065-03515 RING 1
11 3890-12110 DRUM 1
12 04064-01210 RING 1
13 3890-13100 GEAR COMP 1
14 3890-13110 • GEAR 1
15 3890-13121 • SHAFT 1
16 3890-13131 GEAR 1
17 3890-13140 SHAFT 1
18 04010-00310 KEY 1
19 3890-13210 SHAFT 1
20 0224-00610 BOLT 1
21 01641-20608 WASHER 1
22 3310-12281 BOLT 4
23 0225-10616 BOLT 4
24 3890-14100 HANDLE COMP 1
25 3890-14110 • HANDLE 1
26 3541-14221 • GRIP 2
27 0225-30616 • BOLT 4
28 3524-14400 LEVER 1
Key# Part Number Description Q'ty
17 
