Raypak SureRack Kit 302B-2342B - Manual

Catalog No.: 1000.92D Effective: 11-15-07 Replaces: 8-15-07
A
B
w
Job:
Engineer:
Contractor:
Prepared By:
Model: Date:
Features
Two-boiler Vertical Stack
No Vent Offset Required
Small Footprint
Low Ceiling Height
Heavy Duty Construction
Seismic Zone 4
SureRack™ Kit
Stacking System for
Hi Delta
®
Boilers
Models 302B-2342B
SureRack Kit (X-1)
Dimensions (in.) Hi Delta
Model
Part
No.
Weight
(lbs.) A B W
Cross
Beams
Seismic
Zone 4
Add-On
(X-2)
Stacked
Boiler
Height (in.)
302B 006906 201 41-1/4
402B 006907 214 48-1/4
502B 006908 228 55-1/4
652B 006909 257 65-3/4
752B 006910 265 72-3/4
902B 006911 276
30
83-1/4
CTR. 3
PN
007046
72-1/4
992B 011563 340 64-1/8 16-13/16
1262B 011564 361 75-1/2 20-9/16
1532B 011565 371 87 26-3/8
1802B 011566 408 98-1/8 30-1/8
2002B 011567 430 109-1/2 33-15/16
2072B 011567 430 109-1/2 33-15/16
2342B 011568 458
37-1/2
121 37-11/16
4
PN
007053
87-1/2
