HD74LV2GT14A
Rev.2.00, Oct.16.2003, page 6 of 9
Switching Characteristics
•
V
CC
= 3.3 ± 0.3 V
Ta = 25°C Ta = –40 to 85°C
Item Symbol Min Typ Max Min Max Unit
Test
Conditions
FROM
(Input)
TO
(Output)
— 7.5 12.5 1.0 14.5 C
L
= 15 pF Propagation
delay time t
PLH
t
PHL — 10.0 15.0 1.0 17.0
ns
C
L
= 50 pF
A or B
Y
•
V
CC
= 5.0 ±0.5 V
Ta = 25°C Ta = –40 to 85°C
Item Symbol Min Typ Max Min Max Unit
Test
Conditions
FROM
(Input)
TO
(Output)
— 5.0 7.6 1.0 9.0 C
L
= 15 pF Propagation
delay time t
PLH
t
PHL — 6.5 9.6 1.0 11.0
ns
C
L
= 50 pF
A
Y
Operating Characteristics
•
C
L
= 50 pF
Ta = 25°C
Item Symbol V
CC
(V) Min Typ Max Unit Test Conditions
Power dissipation
capacitance C
PD
5.0 — 10.0 — pF f = 10 MHz
