Subaru Robin Power Products Subaru EX27 - Manual (Page 19)

EH6 4 EH6 5 EH7 2 EH7 2 L P/ NG EH7 2 F I
Type Overhead Valve Overhead Valve Overhead Valve Overhead Valve Overhead Valve
Bore X Stroke (mm) 80 x 65 80 x 65 84 x 65 84 x 65 84 x 65
Displacement (cc) 653 653 720 720 720
Maximum Output (HP/RPM) 20.5/3600 SAE Test Code J1940 (Gross) 22.0/3600 SAE Test Code J1940 (Gross) 25.0/3600 SAE Test Code J1940 (Gross) 25.0/3600 SAE Test Code J1940 (Gross) 28.0/3600 SAE Test Code J1940 (Gross)
Lubrication Type Pressure System Pressure System Pressure System Pressure System Pressure System
Oil Capacity (oz./cc) 52oz./1550cc 52oz./1550cc 52oz./1550cc 52oz./1550cc 52oz./1550cc
Fuel Tank Capacity (qt./L) N/A N/A N/A N/A N/A
Dimensions (LxWxH) mm 317 x 477 x 475 317 x 477 x 475 317 x 477 x 475 317 x 477 x 475 317 x 477 x 475
Dry Weight (lbs./kg.) 97/44 101/46 101/46 101/46 101/46
SP-17 0 SP-210 E A175 V E A19 0V
Type Chain-Driven OHC Chain-Driven OHC Vertical Chain-Driven OHC Vertical Chain-Driven OHC
Bore X Stroke (mm) 67 x 48 67 x 60 68 x 48 68 x 52
Displacement (cc) 169 211 174 189
Maximum Output (HP/RPM) 5.7/4000 SAE Test Code J1349 (Net) 7.0/4000 SAE Test Code J1349 (Net) 4.5/3600 SAE Test Code J1349 (Net) 5.5/3600 SAE Test Code J1349 (Net)
Lubrication Type Splash with Chain Carry Splash with Chain Carry Splash with Chain Carry Splash with Chain Carry
Oil Capacity (oz./cc) 20oz./600cc 20oz./600cc 20oz./600cc 20oz./600cc
Fuel Tank Capacity (qt./L) 3.8 qt./3.6 L 3.8 qt./3.6 L 1 qt./1 L 1 qt./1 L
Dimensions (LxWxH) mm 304 x 354 x 335 311 x 366 x 335 397 x 360 x 268 425 x 360 x 290
Dry Weight (lbs./kg.) 33/15 35/16 29/13 29/13
