Page 5
5
ARP-900E / ARP-900DE
INSTALLATION
Installation of the exhaust pipe
This unit is portable and may be moved from room to room. Please follow
the steps for proper installation:
1. Feed the outward adapter through the extendable window spacer.
2. Twist the exhaust hose into the outward adapter.
3. Insert the window spacer into the window gaps as shown. Adjust its
length if necessary.
4. Slide window across so that the spacer is held securely.
NOTE: Install window vent vertically or horizontally depending on window style.
Window Spacer may be cut to fit. If window spacer does not fill opening
completely a custom made spacer from your local home improvement store
can be made.
Extendable
window
spacer
FIG.5
FIG.6
FIG.7
Outward Adapter
