PORTABLE PROJECTION SCREENS
CINEMOBIL
Portable projection screen in an appealing design
for all projection types.
To be installed on the floor or on a table.
Projection screen with black border in 1:1 or 4:3
format with light-proof rear side is available in
various sizes.
Product details:
• V-shaped tube in elegant design with
integrated carrying handle.
• Easy and fast installing and removing.
• Particularly suited for mobile use since the
fabric is perfectly protected when retracted
in the casing.
• Very plain position due to tensioning
mechanism (sturdy roll-up mechanism).
• Continuously adjustable and easy-to-operate
telescopic tripod. It can be locked at the
bottom side for an easy transportation.
• Continuous black border for improved picture
framing.
• Light-proof rear coating for use even in front
of a window.
• High-quality AlphaLux fabric with a large
viewing angle.
Collar for tripod tube Retracted screen Lock head Retracting mechanism Clip to attach the tripod tube
to the casing bottom Keystone eliminator
Cinemobil – Technical data (all dimensions in cm)
Ref. no. Type Fabric Format A B C D R1 R2 R3 E F G H J Weight
84214 Cinemobil 120x90 Alphalux 4:3 124 143 120 90 2 2 51 134 8.5 24.5 153 132 9.5 kg
84211 Cinemobil 120x120 Alphalux 1:1 124 172 120 120 2 2 50 134 8.5 24.5 182 132 10 kg
84224 Cinemobil 160x120 Alphalux 4:3 164 172 160 120 2 2 50 174 8.5 24.5 182 172 12 kg
84221 Cinemobil 160x160 Alphalux 1:1 164 193 160 160 2 2 31 174 8.5 24.5 203 172 12.5 kg
84234 Cinemobil 180x135 Alphalux 4:3 184 200 180 135 2 2 63 194 8.5 24.5 210 192 13.5 kg
C
B
F
D
R 1
R 2
R 3
H
E G
J
A
13
