Specifications – Runco VX-4000d User Manual

Page 41

Specifications

VX-4000d Projector:

Projector Type:

Digital Light Processing™ (DLP™), Single HD-2+ DMD™ Chip

Native Resolution:

1280 x 720 (Designed for 16:9 screens only)

Aspect Ratios:

Determined by supplied processor

Video Standards:

NTSC, PAL

DTV Compatibility:

480p, 720p, 1080i

Scan Frequency:

Horizontal: 15-81 kHz
Vertical: 43-100 Hz

Picture Size:

Recommended Width: 72-96 in.

(16:9 screen)

Maximum Width: 200 in.

Throw Distance:

Lens Option 1: Zoom: 1.20 - 1.40 x width

(Factor x Screen Width)

Lens Option 2: Zoom: 1.40 - 1.77 x width
Lens Option 3: Zoom: 1.77 - 2.35 x width
Lens Option 4: Zoom: 2.35 - 3.60 x width
Lens Option 5: Zoom: 3.60 - 5.70 x width
Lens Option 6: 0.67 x width (for rear-screen applications)

Horizontal / Vertical Offset: Horizontal offset varies per lens, up to 71%

Vertical offset varies per lens, up to 120%

Light Output:

CSMS Specifications:
Home Theater Calibration: 451-780 ANSI Lumens
Foot-Lamberts: 16.9-29.2
1600 ANSI Lumens

Contrast Ratio:

CSMS Contrast Ratio: 220:1 to 237:1
3400:1 to 4000:1

Lamp:

250W NSH

Lamp Life:

2000 hours @ 6500

Kelvin

Inputs:

(1) RGB HV, (1) DVI w/HDCP, (1) RS-232

12V Output:

See Controller for specifications

Power Requirements:

100-240V AC, 50/60 Hz, 380W

Operating Environment:

40°- 95° F, (5°- 35° C), 0%-90% Humidity (non-condensing)

Dimensions:

Width: 20 7/8 in. (530 mm)

(w/out feet)

Depth: 27 7/8 in. (708 mm)
Height: 8 7/8 in. (225.4 mm), with feet 9 7/8 in. (250.8 mm)
Weight: 73 lbs. (33.1 kg) (without lens)

Regulatory Approvals:

Complies with FCC Class B, CE, C-Tick

Limited Warranty:

Projector: (2) Two year parts and labor from the date of delivery to the
end user.
Lamp Warranty: 1000 hours or (6) six months, which ever comes first.
