– 18 –
I
N
S
T
A
L
L
A
T
I
O
N
® ®
Bass
Right
Gain
Right
Input
Left
Input
Left
Gain Treble
+ –
+ L –
Speaker
+ R –
Speaker
RCA Input
4 Ω m i n .
Mono Operation
• RCA inputs are connected to both left and right channels
• Gain for left and right channels are set equally to balance
the subwoofer
• Impedance for mono channel should be 4
Ω
minimum
• XCard can be set for High-Pass, Low-Pass or Full Range
