fl at panel solutions

Wall Mount for LCD, Plasma, and
LED Displays

Installation Manual

MAF75BKR

Fits TVs 26”- 40”

Maximum Load

Capacity – 100 lb (45 kg)

Thank you for choosing the RCA MAF75BKR Universal Flat Panel
TV Wall Mount. This mount can be used for all major brands of
26" - 40" fl at panel TVs, 100 lbs (45 kg) or under. This wall mount
features a 0-15-degree tilt for easy viewing. Before attempting
to mount your television set, please remove all parts from this
package and read the installation instructions carefully.

WARNING: Use of this mount with a TV weighing over 100
lbs. or with a screen larger than 40" could cause the mount
to fail causing property damage and/or personal injury.

1.

Read these instructions carefully before you begin.

If you are unsure of any part of the process, contact
a professional contractor or installer for assistance.
Improper installation can result in injury or damage.

2.

The wall or mounting surface must be capable of

supporting the combined weight of the mount and
the display; if not, the structure must be reinforced.

3.

Safety gear and proper tools must be used. Failure

to do so can result in injury and/or damage. A
minimum of two people are required for installation.
Do not attempt to install this mount alone under any
circumstances.

4.

Follow all instructions and recommendations

regarding adequate ventilation and suitable
locations for mounting your display. Consult the
owner‘s manual for your particular display for more
information.

5.

For drywall installation,

it is essential for the

wall mount plate to be attached to wall studs.
(Use a stud fi nder.)

6.

Use the included hardware for mounting purposes.

This hardware has been provided to ensure a safe
and secure mount.

7.

Hire a licensed electrician to relocate an electrical

outlet, if needed.

8.

Be sure to purchase wires long enough to connect

the TV to the audio and video components in your
installation.

Keep your sales receipt to obtain warranty parts and
service and for proof of purchase. Attach it here and
record the model number. This number is located on
the product.

Model No. ____________________________________

Purchase Date _________________________________

Dealer/Address/Phone _________________________

Safety precautions

Follow these precautions to ensure safe installation and mounting of your fl at panel TV.

Tools

Phillips Head Screwdriver

Ratchet or Driver with 13 mm (1/2”) Socket

Electric or Portable Drill

3/16” (4.8 mm) Drill Bit and Stud Finder for Drywall

Installation

3/8” (10 mm) Masonry Bit for Concrete Installation

Package Contents

Wall Plate (x1)

Mount Arm (x2)

Tilt Adjustment Rod (x1)

Safety Bar (x1)

Instruction Manual (x1)

Hardware Kit (x1)

Preparing to install

Before beginning the installation process, verify that you have all the necessary tools on hand. The following
tools are required for proper installation:

Continues on next page...

Pour des instructions
en français, se
reporter à la page 6.

Para obtener
instrucciones en
español, consulte la
página 11.

CAUTION:

This wall mount is intended for use
only with the maximum weight of
45 kg/100 lbs. Use with heavier
than the maximum weights
indicated may result in instability
causing possible injury. Follow
the installation and operation
instructions carefully.
