High Sensitivity GPS-6021-X6 Operating Manual
Rikaline
Rikaline International Corp. 10F, 64, Kang-Ding Road, Taipei 108, Taiwan
Tel: ++886 2 2370 4688 Fax: ++886 2 2370 4686 E-Mail: [email protected] Web: www.rikaline.com.tw
7
3. Hardware interface
3.1 Dimension
Size: 83.0(H) x 47.5(W) x 14.5(D) (mm)
3.27"(H) x 1.87"(W) x 0.57"(D).
3.2 Hardware Interface
The GPS-6021-X6 includes an antenna in a unique style gadget. Simply put it into a CF card slot or
insert it into PCMCIA slot through a PCMCIA adapter of any type of PC with Windows OS. The interface is
through a standard 50-pin PCMCIA connector with RS-232 level.
.3 Connector
1) Standard 50-pin CF female connector.
2) Optional active antenna female connector.
3.3.1 Function definition of CF card connector
Please download detail at http://compactflash.org/specdl1.htm
3.4 Accessories
3.4.1 Active Antenna
A-10302-M Active Antenna with 2 meter 180° MMCX connector
A-10305-M Active Antenna with 5 meter 180° MMCX connector
