Subaru Robin Power Products PKX301 User Manual
Page 9
PKX301 - 9 - 07-03
SECTION 2
CRANKCASE GROUP
REF. PART NO. DESCRIPTION QTY. REMARKS FROM-TO FIG.
Gasket Sets include the following:
Fig. 200 items 90, 280, 620 and 690
Fig. 400 items 340 and 550
10 277-10102-41 CRANKCASE
CP
1
5692~ 200
277-10102-31 CRANKCASE
CP
1
~5691 200
20 237-14201-03 VALVE
GUIDE
2
200
26 277-16010-01 STEM
SEAL
1
200
30 044-02502-00 OIL
SEAL
1
200
40 060-02800-21 BALL
BEARING
1
5692~ 200
060-02800-20 BALL
BEARING
1
~5691 200
50 277-15011-03 PIPE
KNOCK
2
200
60 010-50802-50 STUD
2
200
70 010-50603-51 STUD
2
200
75 044-00600-20 OIL
SEAL
1
200
80 040-11400-30 PLUG
2
200
90 021-11400-20 GASKET
2
200
210 277-11001-31
MAIN BEARING COVER
1
5692~ 200
277-11001-21
MAIN BEARING COVER
1
5753-5691 200
277-11001-11
MAIN BEARING COVER
1
~5752 200
220 044-02502-10 OIL
SEAL
1
200
230 060-02501-40 BALL
BEARING
1
5692~ 200
060-02500-10 BALL
BEARING
1
~5691 200
250 277-45004-21 GOVERNOR
GEAR
1
200
260 263-41901-03 GOVERNOR
SLEEVE
1
200
270 277-63601-13 OIL
GAUGE
1
200
275 277-65001-03 FILLER
PLUG
1
200
280 021-31600-20 GASKET
1
200
281 021-31600-20 GASKET
1
200
300 001-04083-50 FLANGE
BOLT
6
200
610 277-13001-01 CYLINDER
HEAD
1
200
620 277-15001-13 GASKET,
HEAD
1
200
630 011-00802-40 FLANGE
BOLT
4
200
631 001-04083-50 FLANGE
BOLT
1
200
680 277-15501-01 ROCKER COVER CP
1
200
690 277-16001-03 GASKET, ROCKER COVER
1
200
700 277-15011-03 PIPE
KNOCK
2
200
710 011-00600-20 FLANGE
BOLT
4
200
960 227-99001-07 GASKET
SET
1
200
