Specifications
Model WM-24 WM-30
Frequency
Response: 50Hz-20kHz ±3dB 45Hz-20kHz ±3dB
Sensitivity: 90dB 90dB
Recommended/
Rated Power: 75-120 Watts 75-120 Watts
Woofer(s): (2) 4” Active Aluminum Cone
(2) 4” Passive Aluminum Cone (2) 4” Active Aluminum Cone
(2) 4” Passive Aluminum Cone
Tweeter: (1) 1” Fabric Dome (1) 1” Fabric Dome
Impedance: 6 Ohms 6 Ohms
Crossover
Frequencies: 3000 Hz 3000 Hz
Finish: Black Brushed Aluminum Black Brushed Aluminum
Grille: Black or Silver Cloth Black or Silver Cloth
Dimensions: 7
1
/
8
” W x 24” H x 3
3
/
4
” D
(182mm W x 610mm H x 95mm D)
7
1
/
8
” W x 30” H x 3
3
/
4
” D
(182mm W x 762mm H x 83mm D)
Weight: 9½ lbs. (4.30 Kg) 11 lbs. (4.98 Kg)
Bracket
Dimensions: 15¼” H x 2” W x ½” D
(387mm H x 51mm W x 13mm D) 15¼” H x 2” W x ½” D
(387mm H x 51mm W x 13mm D)
