9 110939
OWNER’S MANUAL
For more information, visit www.desatech.com
PARTS LIST
ELECTRIC POLE TRIMMER
MODEL 110946-01
This list contains replaceable parts used in your electric Pole Trimmer. When ordering parts,
be sure to provide the correct model number (from the model plate), then the part number and
description of the desired part.
KEY PART
NO. NO. DESCRIPTION QTY.
1 110909-01 Top Motor Housing 1
2 075499 Roller Bearing 1
3 110917-01 Motor Set (armature and field) 1
4 110920-01 Gear/Shaft Assy. 1
5 110911-01 Pivot Bracket 1
6 076744 1/4-20 x 2.00" Cap Screw 2
7 110941-01 Rubber Plug Seal 1
8 110932-01 O-Ring (AS 568 #-012) 1
9 110912-01 Pivot Spool 1
10 110926-01 E-Clip 1
11 110933-01 Compression Spring 1
12 110924-01 Lock Rod/Knob Assy. 1
13 110923-01 Pivot Stud 1
14 110925-01 .25 Push Nut 1
15 110913-01 Hand Guard 1
16 110922-01 Cutter Blade Assembly 1
17 110921-01 Cam 1
18 110910-01 Bottom Motor Housing 1
19 059046 Screw, PPH, B, 8-18 x .88 12
20 110914-01 Bottom Cover 1
21 110929-01 8-32 x 2" PH, PR Screw 5
22 110942-01 Fiberglass Pole with Grip 1
23 110934-01 Internal Power Cord 1
24 110906-01 Left Trigger Housing 1
25 110908-01 Lock ON/OFF lever 1
26 107694-01 Compression Spring 2
27 107729-01 Micro Switch 1
28 110907-01 Trigger Lever 1
29 110905-01 Right Trigger Housing 1
30 111249-02 Shrouded Power Cord 1
31 103880-01 1/4-20 Lock Nut 2
