FEATURES
Fig. 1
PRODUCT SPECIFICATIONS
Maximum Cutter Diameter . . . . . . . . . . .1-1/8 in. (29 mm)
Collet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1/4 in. (6 mm)
No Load Speed . . . . . . . . . . . . . . . . . . . . . . . . 25,000/min. Input . . . . . . . . . . . . . . . 120 V, 60 Hz, AC only, 4.5 Amps
Net Weight . . . . . . . . . . . . . . . . . . . . . . . . .3 lbs. (1.36 kg)
Cord Length . . . . . . . . . . . . . . . . . . . . . . . . . . .10 ft. (3 m)
WRENCHES
ON-OFF SWITCH
MOTOR
HOUSING
LAMINATE
SUB-BASE
BASE
COLLET NUT
DEPTH OF CUT
SCALE
DEPTH
ADJUSTMENT
LATCH
��
�� ��
�
�
���
���
���
�
WOODWORKING
SUB-BASE
SUB-BASE
HANDLES
