RCA F20648 - Manual (Page 4)

➤Audio/Video Monitor Panel
Color-coded monitor panel
provides direct audio and video
connections for optimum
performance and system flexibility.
Includes audio/video input, one
S-Video input, plus switchable
audio outputs for fixed and
variable level control.
• One Pair of Switchable
(Variable/Fixed) Audio
Outputs
Connect TV to an external audio
source with speakers (AV receiver,
subwoofer, power amplifier) to
create a true home theater setup.
Switchable outputs offer maxi-
mum flexibility for connecting
various types of external audio
components.
➤Front Audio/Video Inputs
The front jacks allow for the
convenient connection of
components such as game
systems, camcorders, digital
cameras, and other A/V
components.
• G-LINK 1 Connector
The G-LINK 1 connector allows
the GUIDE Plus+ GOLD 1 Program
Guide to work with your VCR
(enabling one-touch record)
and/or cable box (ability to tune
directly to a station when the
program guide is on your
TV screen).
➤S-Video Input
Direct Y/C input connects TV to
compatible S-Video source (e.g.,
DVD player, RCA
® -DIRECTV ™
System, S-VHS VCR/Hi8 VCR/
camcorder, or Internet set-top
device) for high-resolution playback.
• Front Panel
• Back Panel
1 GUIDE Plus+ GOLD and G-LINK are trademarks of Gemstar-TV Guide International, Inc.
2 Check your cable company’s compatibility requirements.
3 dbx is a registered trademark of Carillon Electronics Corporation.
4 This television receiver provides display of television closed captioning in accordance
with §15.119 of the FCC rules. This television receiver does not support color attributes
of television closed captioning.
VIDEO
R L / MONO
S-VIDEO
AUDIO
R L
CABLE/
ANTENNA
G-LINK
IN
OUT
• Limited Warranty
– 90 days for labor charges.
– One year for parts.
– Two years for picture tube.
– See RCA dealer or visit www.rca.com for complete details.
Connections
Specifications
F20648
Screen Size (diagonal) 20"
Finish Ebony Texture
Cabinet Dimensions 19 1 ⁄
8
" H, 20 1 ⁄
4
" W, 18 7 ⁄
8
" D
Approx. Shipping Weight 54 Lbs.
©2001 Thomson multimedia Inc.
Form S-F20648
Trademark(s) ® Registered
Marca(s) Registrada(s)
Photos and features subject to change
without notice. Illustration of product finish
may vary from actual color. Screen sizes
measured diagonally.
Printed in the U.S.A. 3/01
PC15892
GAC38656
