11. Insert two 1 1/2Ó Square Inner Caps (31) into the
ends of the Leg Lever (17). Insert a 1Ó Round Inner
Cap (39) into the weight tube on the Leg Lever.
Press a 1Ó Angled Outer Cap (38) onto the other end
of the weight tube.
Attach the Leg Lever (17) to the Adjustable Bench
Leg (2) with a 3/8Ó x 3Ó Bolt (21) and a 3/8Ó Nylon
Locknut (11).
12. Insert 3/4Ó Round Inner Caps (26) into the ends of
the three Pad Tubes (16).
Insert two Pad Tubes (16) through the holes in the
Leg Lever (17). Slide a Foam Pad (25) onto each
side of the Pad Tubes.
Insert a Pad Tube (16) through the upper tube on the
Adjustable Bench Leg (2). Slide a Foam Pad (25)
onto each side of the Pad Tube.
11
Weight
Tube
39
31
21
11
38
31
17
2
12
17
26
25
25 2
26
25
16
25
25 26
14. Make sure all parts are properly tightened before
you use the weight bench. The use of the remaining
parts will be explained in ADJUSTING THE WEIGHT
BENCH on pages 13 and 14 of this manual.
13. Attach the Curl Pad (8) to the Curl Upright (9) with
two 1/4Ó x 3/4Ó Screws (3) and two 1/4Ó Washers (30).
13
30
3
30 9
8
