FCC Information

This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference,
and (2) this device must accept any interference
received, including interference that may cause
undesired operation.
In accordance with FCC requirements, changes
or modifications not expressly approved by
Thomson Inc. could void the user’s authority to
operate this product.
This device generates and uses radio frequency
(RF) energy, and if not installed and used properly,
this equipment may cause interference to radio and
television reception.
If this equipment does cause interference to radio
or television reception (which you can determine by
unplugging the unit), try to correct the interference
by one or more of the following measures:
• Re-orient the receiving antenna (that is, the
antenna for the radio or television that is “receiving”
the interference).
• Move the unit away from the equipment that is
receiving interference.
• Plug the unit into a different wall outlet so that the
unit and the equipment receiving interference are
on different branch circuits.
If these measures do not eliminate the interference,
please consult your dealer or an experienced radio/
television technician for additional suggestions.
Also, the Federal Communications Commission
has prepared a helpful booklet, “How To Identify
and Resolve Radio TV Interference Problems.”
This booklet is available from the U.S. Government
Printing Office, Washington, DC 20402. Please
specify stock number 004-000-00345-4 when
ordering copies.

For Your Safety

The AC power plug is polarized (one blade is
wider than the other) and only
fits into AC power outlets one
way. If the plug will not go into
the outlet completely, turn the
plug over and try to insert it the
other way. If it still does not fit,
contact a qualified electrician to change the outlet,
or use a different one. Do not attempt to bypass
this safety feature.

The descriptions and characteristics in this owner’s manual
are for the purpose of general reference only and not as a
guarantee. In order to provide you with the highest quality
product, we may make changes or modifications without prior
notice. The English version serves as the final reference on
all product and operational details should any discrepancies
arise in other languages.

• Make sure that you keep your set away

from water and high temperatures.

• Do not use your System immediately

after transporting it from a cold place
to a warm place, as condensation may
cause the system to malfunction.

• Keep your unit away from humid

areas and abnormally hot places.

• To prevent personal injury, do not

reverse any batteries.

• The use of apparatus in moderate

climates.

• The apparatus shall not be exposed to

dripping or splashing and that no
objects filled with liquids, such as
vases, shall be placed on the apparatus.

• No naked flame sources, such as

lighted candles, should be placed on
the apparatus.

• Attention should be drawn to the

More Information

Notes

Main plug is used as the disconnect device, it

shall remain readily operable and should not

be obstructed during intended used. To be

completely disconnected the apparatus from

supply mains, the main plug of the apparatus

shall be disconnected from the mains socket

outlet completely.

Superadio

High Performance, Long Range
AM/FM Portable Radio
Radio AM/FM portative à haute
performance et à longue distance

SERVICE

This product should be serviced only by those
specially trained in appropriate servicing
techniques. For instructions on how to obtain
service, refer to the warranty included in this
Guide.
Attach your sales receipt to the booklet for future
reference or jot down the date this product was
purchased or received as a gift. This information
will be valuable if service should be required
during the warranty period.

Purchase date:
Name of store:

environmental aspects of battery
disposal.

• Minimum distances (2cm) around the

apparatus for sufficient ventilations.

• The ventilation should not be

impeded by covering the ventilation
opening with items, such as newspaper,
table-cloths, curtains, etc.

• The rating plate is located at the

bottom cabinet of apparatus.

Ecology

Help protect the environment - we recommend
that you dispose of used batteries by putting
them into specially designed receptacles.

Maintenance

Clean the unit with a soft cloth, or a damp
chamois leather. Never use solvents.

LONG-RANGE RECEPTION

Tuned RF on both AM and FM.

38” (976 mm) FM Swivel Whip Antenna.

7-7/8” (200 mm)AM Ferrite Rod Antenna.

STATION SELECTIVITY AND SEPARATION

Ceramic IF Filter, plus 3 IF Tuned Circuits on FM.

4 IF Tuned Circuits on AM

Switchable AFC (Automatic Frequency Control)

Precision Vernier Tuning

BEST SOUND QUALITY

6-1/2” High-sensitivity speaker, plus 2” Tweeter

700 mw PMS Audio Output

Separate BASS and TREBLE Controls

Separate VOLUME Control

BEST SOUND QUALITY

6 “D” cell battery power (batteries not included) or AC
household power operation.

FM-AM IC (Integrated Circuit)

Separate power ON-OFF Switch

Headphone Jack for optional headphones

Fold down carry handle

AM-FM External Antenna Terminals

This radio offers a level of performance above the average
portable radio. We urge you to follow the step-by-step
instructions in order to enjoy the full capabilities of this
radio.

Controls and Features

1. FM WHIP ANTENNA (replaceable) - Lift and

extend to full length.

2. POWER ON/OFF SWITCH - Use to turn radio

ON or OFF.

3. FM-AM TUNING KNOB - Adjust to select your

favorite AM or FM station.

4. BAND SELECTION SWITCH - Select AM or FM

operation.

5. AFC SELECT SWITCH - Switch off to Fine Tune

then Switch on to assure drift-free FM reception.

6. HEADPHONE JACK - For private listening with

optional headphones.

7. VOLUME CONTROL - Adjust for desired

listening level.

8. BASS TONE CONTROL - Adjust to preferred

listening taste.

9. TREBLE TONE CONTROL - Adjust to preferred

listening.

10. WIDE BAND SELECT SWITCH - NORMAL: for

maximum selectivity of adjacent stations WIDE:
for increased audio fidelity of strong local stations

11. FM-AM DIAL SCALE - Indicates frequency of

FM or AM station being received. The Log Scale
helps to locate broadcasts.

1

2

3
4
5

6

7

8

9

10

11

1

2

3
4
5

6

7

8

9

10

11

5637 8280 (EN/E/F)

FM-AM OPERATION

1. Turn radio ON by depressing the POWER

ON-OFF switch.

2. Select AM or FM operation with the BAND

SELECT switch.

3. For FM reception, lift and extend the Whip

Antenna to its fullest length.

4. Turn the volume up by rotating the VOLUME

Control in a clockwise direction.

5. Rotate the FM/AM TUNING knob to select

your favorite FM or AM station.

6. Precise tuning to distant (or weak) FM

stations can be achieved by following

the AFC (Automatic Frequency Control)

directions.

7. Adjust the VOLUME, BASS and TREBLE

controls to your preferred listening level and

tone.

8. To turn radio off, press the POWER ON-OFF

switch again.

AM BAND

AM Band radio stations are assigned broadcast

frequencies between 540 and 1700 Kilohertz

(KHz). AM transmissions leave the antenna in

two types of radio waves - ground waves and

sky waves. Ground waves stay close to the

ground and can be picked up by receivers in the

local area, Sky waves go into the sky and pass

thru the ionosphere into outer space. Some sky

waves have a tendency to “bounce” back from

the ionosphere (especially during the evening

hours) and can be picked up by distant receivers.

WIDE BAND

This “AM ACCENT” switch allows:

• Maximum selectivity of adjacent stations in

the NORMAL position.

• Improved audio fidelity of strong local

stations when in the WIDE positon.

NOTE: In the WIDE position, you may encounter

beat and whistle noises due to adjacent-channel

stations in the AM band. This problem may be

particularly noticeable during nighttime reception.

If this occurs, switch to NORMAL positon.

FM BAND

FM Band radio stations broadcast on assigned

frequencies between 88 and 108 Megahertz

(MHz). FM broadcasts are higher frequencies

and offer less static and interference from

Operations

Power Supply

This Two-Way portable radio operates on AC
Household power or 6 “D” size batteries with
automatic AC/DC switching. The batteries are
not included with radio and power cord are
house in a compartment on the back of the radio.

BATTERY OPERATION

1. Gently place the radio on its front with the

bottom facing you.

2. Remove the battery/cord storage

compartment door by releasing the three
compartment door latches then swing door
toward you and off

3. Insert the 6 “D” size batteries into the

compartment as indicated on the panel
inside the compartment. Be sure the +
(cap) end of each battery is installed in the
direction shown in the battery outline. Insert
“bottom row” of batteries first then slide the
“top row” under the BATTERY STRAP from
the left side of cabinet.

4. Replace the compartment door by first

placing the bottom securing tabs into their
receptacles, then swing door into position
and press until the three latches “snap” into
place.

NOTE: After a portable radio has been used
extensively in battery operation, the quality of
the sound may deteriorate or the loudness may
decrease. When this happens, the very first thing to
suspect is run-down batteries.
Further confirmation that the batteries are run down
can be made by changing to AC line cord operation.
If the sound quality improves the batteries are run
down and should be replaced with new batteries.
Your SUPERADIO offers exceptional battery life
with standard “D” size batteries. Alkaline batteries,
although more expensive, offer increased battery life
over standard cells.

IMPORTANT
Since few batteries are actually “leakproof”, always
remove batteries, (even if new) when storing product
unused for over 30 days or using AC continually.
For shorter periods of AC operation (up to 30 days)
batteries may remain in product.
Always remove worn-out batteries as they may
leak chemicals which will damage the electronic
components and cabinet. When discarding batteries,
be sure to dispose of them in the proper manner,
according to your state and local regulations. ‘

120-VOLT AC OPERATION

Remove power cord from compartment and plug
into any 120-volt AC household outlet. An opening in
the compartment door has been provided to permit
AC operation with the door in place. Your radio will
automatically convert from battery to AC operation.
When finished using radio on AC, be sure to switch
POWER ON-OFF switch to OFF. Removing plug
from household outlet without switching radio to OFF
will automatically revert operation to battery power.

Battery Strap

BUILT-IN AM/FM ANTENNAS

AM -The BUILT-IN ANTENNA (200 mm Ferrite Rod) is somewhat directional, and on weak
stations it may be necessary to rotate the radio for best reception.
The FM WHIP antenna is not used for AM reception.
FM - The WHIP ANTENNA may be positioned anywhere within an 18O degree arc and is capable
of rotating 360 degrees. To use, lift and extend the WHIP to its fullest length. For distant stations, it
may be necessary to adjust the WHIP antenna’s position for best reception.
NOTE: To avoid damaging the WHIP, always lower its sections one at a time starting with the
largest diameter. Never lower the WHIP from the tip end since buckling or bending is possible. Be
sure the slot provided in the base of the swivel antenna is positioned properly before lowering the
WHIP into its holder clip.

WHIP ANTENNA REPLACEMENT

The whip antenna has been designed so that it is easily replaced in the event it is damaged. The
antenna’s mounting post goes through a hole in the cabinet top and is held in place by a single
screw through the cabinet back. Simply remove the screw and slide the post out of the cabinet
top. To install the replacement, reverse the procedure.

EXTERNAL AM/FM ANTENNA TERMINALS

Although the radio normally provides excellent reception utilizing its built-
in antennas, it offers the additional capability of connecting outside AM
or FM antennas to the EXTERNAL ANTENNA terminals on the cabinet
back. External antennas can be used in poor reception areas (inside steel
and concrete buildings) or to improve reception of distant stations. The
antenna required for FM differs from the type needed for AM reception.
AM - An AM antenna for outside installation connects to the screw
terminals on the cabinet back marked AM and GND.
FM - You may use your TV antenna or an outside FM antenna. The twin
leads connect to the screw terminals marked FM (300 ohm) and GND.
IMPORTANT: External antennas are available from local parts stores. Follow all safety instructions
(provided with antenna) when installing any outside antenna.

Antenna

HEADPHONE

You can be alone in a crowd with
optional headphone that lets you listen
in complete privacy. The radio speakers
are automatically silenced when you plug
headphone into Jack located on the right
side of the cabinet.
NOTE: The Jack is designed to permit use of
stereo headphones with your mono radio but
reception will be heard in mono only.

USERS CHECK LIST

Before seeking service a simple review of
the step-by-step instructions may eliminate
or clarify your problem.
• NO SOUND

Is power cord plugged into a working
120V AC outlet? Is POWER ON/OFF
switch in ON (depressed) position? Are
batteries installed correctly? Are batteries
weak?

• WEAK OR DISTORTED SOUND

Check condition of batteries or operate
on AC power. If sound is good on AC
power, batteries are weak and should be
replaced.

AM Reception - Try rotating radio for best
reception

FM Reception - Fully extend whip
antenna.

• EXCESSIVELY NOISY RECEPTION

The “noise” may be coming from outside
sources such as the broadcast program
material, electrical “noise” from nearby
automobiles, electrical lights

(Fluorescent lamps), etc, also, noise will
be more noticeable from distant stations.

PERSONAL STATION LOG

Because of the long-range performance of this radio, you may enjoy keeping track of distant
stations you have received.
The Log Scale helps in locating stations by providing a reference point. Just jot down the log scale
number, the station frequency, and time of reception from each station on a chart such as that
shown below. You will soon have a complete log of transmissions that you receive in your location.

City Station call letters AM KHz, F-MHz Log scale Date Time

Have a Blast-Just Not in your
eardrums!
Make sure you turn down the
volume on the unit before you
put on headphones. Increase
the volume to the desired level only after
headphone are in place.

Important: Also keep your “Bill of Sale” as proof of purchase.
Important: Veuillez conserver votre “Facture D’achat” comme preuve d’achat.
Importante: Guarde su “Boleta de venta” como prueba de su compra.

FOR SERVICE AND REPAIR, PLEASE VISIT

POUR ENTRETIEN ET RÉPARATION, VEUILLEZ VISITE

PARA SERVICIO Y REPARACIÓN, POR FAVOR VISTITA

© 2008 AVC MULTIMEDIA

Model no.
N° du modèle
N° de modelo

Type of set
Type d’appareil
Tipo de aparato

Serial no.
N° de série
N° de serie

Date purchased
Date d’achat
Fecha de compra

Product name
Nom du produit
Nombre del producto

Invoice no.
N° de la facture
N° de recibo

Dealer name
Nom du marchand
Nombre del comerciante

www.1800customersupport.com/RCA

810-00000WWXXX

In the event your product requires repair after the limited warranty period has expired, please contact our Customer Support Center at

www.1800customersupport.com/RCA

Hours: Monday–Thursday: 9am–7pm, Friday: 9am–5pm, Saturday: 9am–NOON Eastern time.

Important:
You are responsible for any transportation, shipping or insurance relative to the return of product to our Product Returns Center.

Out of Warranty

AVC MULTIMEDIA (“AVC”) makes the following limited warranty. This limited warranty extend to the original consumer purchaser and is limited to
non-commercial use of the product.

One Year Parts & Labor Warranty
AVC products purchased in the United States are warranted to be free from defects in materials or workmanship for a period of one year from
the date of their original retail purchase. If the unit fails to conform to this warranty, we will service the product using new or refurbished parts and
products, at AVC’s sole discretion.

During a period of one year from the effective warranty date, AVC will provide, when needed, service labor to repair a manufacturing
defect at its designated Service Center. To obtain warranty service in the Untied States, you must first call our Customer Support Center at
www.1800customersupport.com/RCA, during the hours listed in the box below. The determination of service will be made by AVC Customer Support.
PLEASE DO NOT RETURN YOUR UNIT TO AVC WITHOUT PRIOR AUTHORIZATION. New or remanufactured replacements for defective
parts or products will be used for repairs by AVC at its designated Service Center for one year from the effective warranty date. Such replacement
parts or products are warranted for an additional one year from the date of repair or replacement. The Customer will be required to ship the unit
to the Service Center indicated at the time Customer Support is contacted to make the necessary repairs. The customer is responsible for all
transportation charges to the service facility.
Packaging and Shipping InstructionWhen you send the product to the AVC service facility you must use the original carton box and packing material
or an equivalent as designated by AVC

All warranties implied by state law, including the implied warranties of merchantability and fitness for a particular purpose, are expressly limited to
the duration of the limited warranties set forth above. With the exception of any warranties implied by state law as hereby limited, the foregoing
warranty is exclusive and in lieu of all other warranties, guarantees, agreements and similar obligations of manufacturer or seller with respect to the
repair or replacement of any parts. In no event shall AVC be liable for consequential or incidental damages.

No person, agent, distributor, dealer or company is authorized to change, modify or extend the terms of these warranties in any manner whatsoever.
The time within action must be commenced to enforce any obligation of AVC arising under the warranty or under any statute, or law of the United
States or any state thereof, is hereby limited to one year from the date of purchase. This limitation does not apply to implied warranties arising
under state law.

This warranty gives you specific legal rights and you may also have other rights, which may vary, from state to state. Some states do not allow
limitation on how long an implied warranty lasts, when an action may be brought, or the exclusion or limitation of incidental or consequential
damages, so the above provisions may not apply to you.

For more information on other products and services, please visit our web site at

www.1800customersupport.com/RCA

Printed in China

Your Responsibility

Limited Warranty

(1) You must retain the original sale receipt to provide proof of purchase.

(2) These warranties are effective only if the product is purchased and operated in the U.S.A. or Canada.
(3) Warranties extend only to defects in material or workmanship, and do not extend to any product or parts which have been lost
or discarded, or damage to product or parts caused by misuse, accident, improper operation or maintenance, or use in violation
of instructions provided with the product, or to product which has been altered or modified without authorization of AVC, or to
products or parts thereof which have had the serial number removed or changed.

IMPORTER

AVC Multimedia,

Markham, Ontario, L3R 1E3

© 2008 AVC Multimedia

http: //www.1800customersupport.com/RCA

http: //www.rcaaudiovideo.com

outside sources as well as greater audio fidelity than

AM broadcasts. Range, however, is not as great as

AM because very little, if any, sky-wave reception is

involved at FM frequency range.

AFC (Automatic Frequency Control)

Automatic Frequency Conrol (AFC) works to assure

drift-free FM reception and helps to keep the

radio locked-in on the station to which it is tuned.

AFC works only on FM, it does not affect the AM

operation. Tune to the desired FM station with the

AFC SELECT switch in ON position.

Under certain conditions, you may not wish to

use the AFC. When the desired station frequency

is adjacent to a stronger station, the Automatic

Frequency Control may tune the set to the stronger

station. If this occurs, tune in the desired station with

the AFC switch in OFF position. Should switching to

ON cause the set to detune to the stronger adjacent

station, simply leave the AFC SELECT switch in

OFF position.

BASS/TREBLE CONTROLS

The BASS control enables you to increase or

decrease the relative volume of the low-pitched

(bass) sounds from the normal (or “flat”) control

setting.

The TREBLE control enables you to increase or

decrease the relative volume of the high-pitched

(Treble) sounds from the normal (or “flat”) control

setting.

NOTE: These Tone Controls have a large built-in

variation range which will enable you to emphasize

the various tonal sounds and alter the music

you are receiving. You may be able to vary the

musical balance of the music until it is almost

unrecognizable. The Tone Controls were designed

with these extreme range variations to enable you to

adjust for your particular listening preference and the

program being received.

POWER ON-OFF SWITCH

The convenient power ON-OFF push button
switch enables you to set the VOLUME, BASS
and TREBLE controls, then turn the radio on or off
without having to reset the controls each time.

LONG DISTANCE AM LISTENING
(DXing)

Because your radio is designed for long-range
AM reception you will gain added enjoyment
receiving broadcasts from distant AM stations.
You may listen to news, weather, sports, and
other special programming from other cities. A
station log has been included to help you keep
a DX (long distance reception) record of stations
received. Although daytime AM reception is
limited to a maximum of a few hundred miles
(depending on the strength of the radio station,
atmospheric conditions, etc.), at night you may
be able to pick up powerful stations over a
thousand miles away.
This is because AM “sky-wave” signals are
reflected off the ionosphere and back to earth in
the nighttime hours.

DX HELPFUL HINTS

The number of stations you are able to receive
is a function of many factors.
The following may prove helpful:
1. Although the built-in AM antenna will enable

you to receive many distant stations, your
reception can be improved significantly with
the addition of an external AM antenna.

2. The dusk to dawn hours are best for long

distance AM reception with sunrise and
sunset the optimum times.

3. Clear winter evenings are normally superior

to summer because the nights are longer
and there is less interference from electrical
storms.

Abasteciminto de Corriente

Información FCC

Español

Este aparato cumple con la Parte 15 de las

Normas FCC. El funcionamiento de la unidad

está sujeto a las dos condiciones siguientes: (1)

Este aparato no puede provocar interferencias

perjudiciales y (2) este aparato debe aceptar

toda interferencia que reciba incluso aquellas

que provoquen un funcionamiento incorrecto.

De conformidad con los requisitos FCC, los

cambios o modificaciones no aprobados expre-

samente por Thomson Inc. podrían anular la

garantía de funcionamiento de este producto.

Este aparato genera y utiliza energía de radiofre-

cuencia (RF) y si no se instala y utiliza de forma

correcta, este equipo puede provocar interferen-

cias en la recepción de radio y televisión.

Si este equipo provoca interferencias a la

recepción de radio y televisión (lo que puede ser

comprobado desenchufando la unidad) trate de

corregir la interferencia tomando una o más de

las medidas siguientes:

• Reoriente la antena receptora (o sea, la antena

para la radio o televisión que se encuentre

recibiendo la interferencia).

• Aleje la unidad del equipo que esté recibiendo

la interferencia.

• Enchufe la unidad en un tomacorriente de

pared distinto, de modo que la unidad y el

equipo que recibe la interferencia estén en

distintos circuitos.

Si estas medidas no eliminan la interferencia,

por favor consulte con su distribuidor o con un

técnico de radio / televisión experimentado para

que le haga otras sugerencias. Además, la “Fed-

eral Communications Commision” ha preparado

un útil folleto, “How to Identify and Resolve Ra-

dio/TV Interference Problems” (Cómo Identificar

y resolver los problemas de interferencias de

Radio y TV). Este folleto se puede conseguir en

la “U.S. Government Printing Office”, Washing-

ton DC, 20402. Por favor, especifique el número

004-000-0034 cuando se lo solicite.

Para su seguridad

El adaptador de corriente CA
está polarizado (una de sus
patas es más grande que
la otra) y sólo encajará en
salidas de potencia CA de una
manera. Si tiene usted dificultad
en introducir el adaptador en la caja del
tomacorriente en su totalidad, intente cambiar la
posición del adaptador. Si aún así no consigue
encajarlo, contacte a un electricista calificado
para que sustituya la caja del tomacorriente,
o utilice una diferente. No intente pasar
desapercibido estas normas de seguridad.

Las descripciones y las características presentadas en
este documento son dadas a modo de indicación general
y no de garantía. Con el fin de proporcionarle la más alta
calidad de producto posible, nos reservamos el derecho
a hacer mejoras o modificaciones sin previo aviso. La
versión en inglés servirá de referencia para todos los
detalles del producto y del funcionamiento si surgieran
discrepancias en otras lenguas.

• Asegúrese de que mantiene el

equipo lejos del agua y de las altas
temperaturas.

• No utilice el sistema inmediatamente

después de haberlo transportado de
un lugar frío a uno cálido, ya que la
condensación puede hacer que el
sistema no funcione correctamente.

• Mantenga la unidad fuera de áreas

húmedas y de lugares anormalmente
calientes.

• Para prevenir lesiones personales, no

invierta las baterías.

• El uso del aparato en climas moderados.
• El aparato no deberá ser expuesto a

goteo o salpicaduras y objetos que
contengan líquidos, tales como floreros,
no deberán ser colocados sobre el

La clavija principal es usada como el dispositivo

de desconexión. Permanecerá rápidamente

operable y no deberá ser obstruida subida du-

rante el uso que se pretende. Para desconectar

completamente el aparato de la fuente de

poder, la clavija principal del aparato deberá ser

desconectada completamente de la toma de

corriente en la pared.

SERVICIO DE REPARACIONES

Este producto deberá ser reparado
solamente por aquellas personas entrenadas
especialmente en la técnica de su
funcionamiento. Para instrucciones en como
obtener servicio, refiérase a la Garantía en
esta Guía.
Adjunte el recibo de venta a este manual para
una referencia futura, o anote la fecha en que
este producto fue comprado o recibido coma
regalo. Esta información es importante si alguna
reparación fuera necesaria durante el plazo de
la garantia.

Fecha de Compra:
Nombre de la Tienda:

aparato.

• No se deberán colocar fuentes de flama

sin protección, tales como velas, sobre el
aparato.

• Se deberá prestar atención a los aspectos

ambientales de la eliminación de las
baterías.

• Distancias mínimas (2cm) alrededor del

aparato para suficiente ventilación.

• La ventilación no se deberá impedir

cubriendo la apertura de ventilación con
artículos tales como periódicos, paños,
cortinas, etcétera.

• La placa de datos de servicio está situada

en la montura posterior del aparato.

Medio ambiente

Ayude a cuidar el medio ambiente. Le
recomendamos que deseche las baterías
gastadas en los contenedores especialmente
diseñados para ello.

Mantenimiento

Limpie la unidad con un paño suave, o con una
gamuza húmeda. No utilice nunca disolventes.

RECEPCÍON DE LARGO ALCANCE
• RF sintonizado para ambas bandas AM y FM.
• 38” (976 mm) “FM Swivel Whip Antenna” (Antena

FM de Varilla Extensible Giratoria).

• 7-7/8” (200 mm) “AM Ferrite Rod Antenna”

(Antena AM de Núcleao de Ferrita).

SELECTIVIDAD Y SEPARACÍON ESTACIONES
• Filtro “IF” (Frecuencia Intermedia) de Cerámica,

más 3 Circuitos “IF” Sintonizados a banda FM.

• 4 Circuitos “IF” sintonizados a la banda AM.
• Cambiable “AFC” (Control de Frecuencia

Automático).

• “Precision Vernier Tuning” (Nonio Sintonizador

de Precisión).

LA MEJOR CALIDAD SONORA
• Altoparlantes Alto-Sensitivo de 6-1/2”, más

“Tweeter” de 2”.

• Minimo de 700 mw. “RMS” (Raiz cuandrada de

la media cuadrática) de la Audiofrecuencia de
salida.

• Controles separados para “Bass” (Bajo) y

“Treble” (Sobreagudo).

• Control “VOLUME” (Sonoridad) separado.
OTRAS SUPER CARACTERÍSTICAS
• Funciona por medio de 6 pilas tamaño “D” (no

incluidas) o con la corriente casera AC/Alterna.

• FM-AM “IC” (Circuito Integral).
• Interruptor separado para la corriente “ON-OFF”

(Encender Apagar).

• “HEADPHONE JACK” Enchufe para los

auriculares opcionales.

• Asa plegadize para llevar.
• Terminales para la Antenas Externas AM-FM.

Esta radio le ofrece un nivel de actuación muy
superior a la radio portátil corriente. Le rogamos que
siga las instrucciones paso a paso para que Ud.
pueda gozar su radio en su capacidad plena.

Controles y características

Esta radio portátil con Potencia de Doble-Via
funciona con la corriente casera AC/Alterna, o
con 6 pilas tamaño “D”, con un interruptor AC/
DC (Corriente Alterna/Directa) automático. Las
pilas (no incluidas con la radio), y el cordón de
la corriente se guardan en un compartimiento
situado en la parte posterior de la radio.

FUNCIONAMIENTO DON LAS PILAS

1. Suavemente ponga la radio “boca abajo” con

la base de frente a Ud.

2. Quite la puertecilla del compartimiento que

guarda las pilas/el cordón soltando los 3
picaportes de la puertecilla, después haga
girar la puertecilla hacia Ud. y fuera.

3. Inserte las 6 pilas tamaño “D” dentro del

compartimiento de la forma indicada en el
diagrama dentro compartimiento. Asegúrese
de que los extremos o signos (+) de cada
pila sean instalados en la dirección indicada
en el esquema. Inserte primeramente las
pilas “del fondo”, después deslice las “de
arriba” debajo del “Battery Strap” (Cintilla de
las Pilas) por el lado izquierdo del mueble.

4. Vuelva a colocar la puertecilla del

compartimiento prirneramente colocando
las trabillas de seguridad dentro de los
receptáculos correspondiente, después haga
girar la puertecilla en posición y presione
hasta que las 3 picaportes “chasqueen” en
su sitio.

AVISO: Después de que una radio portátil haya
estado funcionando extensivemente usando
las pilas, la cualidad del sonido pueda que se
deteriore o la sonoridad tiende a disminuir.

Cuando ésto suceda, lo primero quo debe sospechar
es que las pilas se están agotando.
Para confirmar que las pilas se estén agotando
cambie of funcionamiento con el cordón de la
corriente AC/Alterna. Si la cualidad del sonido
mejorase, las pilas se encuentran gastadas y deben
ser reemplazadas con unas nuevas.
Su SUPERADIO le ofrece una gran longevidad con
las pilas corrientes tamaño “D”. Las pilas alcalinas,
aunque más caras, también le ofrece más duración
que las pilas corrientes.

IMPORTANTE

Ya que muy pocas pilas son hechas a “prueba de
derrame”, siempre quite las pilas (aunque sean
nuevas) cuando no usa el producto por más de 30
días o cuando usa continuamente la energia CA.
Cuando use la corriente AC/Alterna por poco tiempo
(un máximo de 30 dias) las pilas pueden quedarse
en el aparato.
Siempre quite las pilas gastadas porque éstas
pueden derramar elementos químicos dañinos a los
componenetes electrónicos y al mueble. Cuando
deseche las baterías, asegúrese de deshacerse de
ellas en una manera apropiada, de acuerdo con las
regulaciones locales o del estado.

FUNCIONAMIENTO CON LA

CORRIENTE DE 120 VOLTIOS AC/

ALTERNA

Quite el cordón de la corriente de su compartimiento
y enchúfelo dentrol de cualquier tomacorriente
casero de 120 voltios corriente AC/Alterna. Una
abertura en la puertecilla del compartimiento le
permitirá. Su radio automáticamente convertirá su
función de pilas a corriente AC/Alterna asegúrese de
cambiar el interruptor marcado “POWER ON-OFF”
a la posición “OFF” (Apagado). Una vez que Ud.
desenchufe el enchufe del tomacorriente casero
sin cambiar el interruptor a la posición “OFF”
automáticamente el funcionamiento volverá al uso
de las pilas.

Información sobre seguridad

1. ANTENA FM “WHIP” DE VARlLLA ETENSIBLE

(reemplazable) - Levántela y exténdala a lo

máximo.

2. INTERRUPTOR “POWER” ON/OFF” PARA

ENCENDER/APAGAR - Uselo para encender

“ON” o apagar “OFF” la radio.

3. INTERRUPTOR SELECTOR DE BANDAS -

Para seleccionar la banda AM ò FM.

4. BOTÓN “FM-AM TUNING” SINTONIZADOR -

Ajústelo para seleccionar su estación favorita en

la banda AM ò FM.

5. INTERRUPTOR SELECTOR “AFC” (CONTROL

DE FRECUENCIA AUTOMATICO) - En la

posición ‘off” (apagado) para una sintonización

precisa, después en la posicíon “on” (encendido)

para evitar quo las recepciones FM no se

deriven.

6. “HEADPHONE JACK” - Para escuchar en

privado con los auriculares opcionales.

7. CONTROL PARA LA SONORIDAD - Adjústelo al

nivel auditivo deseado.

8. CONTROL DEL TONO “BASS” (BAJO) -

Adjústelo a su gusto auditivo preferido.

9. CONTROL DEL TONO “TREBLE” (AGUDO) -

Adjústelo a su gusto auditivo preferido.

10. INTERRUPTOR PARA SELECCION DE

BANDA AMPLIA (WIDE BAND) - NORMAL:

para máxima capacidad de selección de

estaciones adyacentes. WIDE: para incremento

en la fidelidad de audio de estaciones locales

potentes.

11. LA ESCALA FM-AM DEL DIAL - Indica el número

de la frecuencia de la estación FM ò AM que

se esté recibiendo. La lista de estaciones “LOG

SCALE” la ayudará a localizar los programas.

Disfrute un estallido musical -

Pero no en sus tímpanos

Antes de ponerse los auriculares,

verifique que ha bajado el

volumen en la unidad. Aumente

el volumen al nivel deseado

únicamente después de haberse colocado los

auriculares.

IMPORTER

AVC Multimedia,

Markham, Ontario, L3R 1E3

© 2008 AVC Multimedia

http: //www.1800customersupport.com/RCA

http: //www.rcaaudiovideo.com

Cintilla
de las
Pilas

This manual is related to the following products:
