RCA Ri338 - Manual (Page 2)

to adjust the Volume
Adjust the VOLUME control to obtain the desired volume.
compatible ipod types
• iPod nano 1st generation 1GB, 2GB, 4GB
• iPod nano 2nd generation (aluminum) 2GB, 4GB, 8GB
• iPod nano 3rd generation (video) 4GB, 8GB
• iPod nano 4th generation (video) 8GB, 16GB
• iPod 5th generation (video) 30GB, 60GB, 80GB
• iPod classic 80GB, 120GB, 160GB
• iPod touch 1st generation 8GB, 16GB, 32GB
• iPod touch 2nd generation 8GB, 16GB, 32GB
Installing the ipod Dock adapter
1. Before connecting your iPod, you need to
install the appropriate iPod Dock Adapter
(The adapter is not included, please use the
adapter that came with your iPod or is sold
separately) in the dock of the unit.
2. Slide the door in the direction shown in
illustration.
3. Insert your iPod Dock Adapter into the dock
until it sits firmly in place.
DC: 9V EXTERNAL DC SUPPLY
BATTERY SUPPLY: “AA” SIZE x 6
connecting to aUX In for Other Sound Sources
You can connect audio devices such as your iPod, CD players or MP3 players to the unit
through the AUX IN jack. Use a Line-In cable (not supplied), connect the AUX IN jack on
the back panel to the Line Out or Earphone jack of the other audio devices.
Listening to the connected Device
Turn on the audio device you have attached to the AUX IN jack, then adjust the volume
of the audio device and the Speaker System.
Inserting your ipod
1. Ensure the appropriate iPod Docking Adapter
is installed.
2. Insert your iPod into the connector in the
dock.
Starting playback
1. Slide the ON/OFF Switch to ON position to turn on the unit and the power indicator
lights up.
2. Now you can enjoy your music by operating the iPod.
notes
• When you are listening to iPod, please disconnect all other audio devices.
• Under AC power supply, the iPod will be charged automatically.
• Under battery operation, the iPod will not be charged.
• Please refer to the user's guide that was included with your iPod for more details.
Specifications and external appearance are subject to change without notice.
Listening to your ipod
aUX In connection
more Information
Limited Warranty
Volume adjustment
Specifications
troubleshooting tips
System doesn’t turn on • Unplug the unit for a moment, and then plug it
back in.
• Check the outlet by plugging in another device.
no sound • Adjust volume setting.
• Make sure you’ve selected the correct function.
ipod does not start play • Make sure the iPod is properly connected to the
dock.
eSD remark:
In case of malfunction due to electrostatic discharge just reset the product (disconnect
and reconnect of the power source may be required) to resume normal operation.
cleaning the exterior
• Disconnect the system from AC power before cleaning the exterior of the unit
with a soft dust cloth.
• Clean the exterior with a soft clean cloth or slightly moistened chamois leather.
DO NOT use solvents as it may cause damage to the unit.
The descriptions and characteristics in this owner’s manual are for the purpose of
general reference only and not as a guarantee. In order to provide you with the highest
quality product, we may make changes or modifications without prior notice. The
English version serves as the final reference on all product and operational details
should any discrepancies arise in other languages.
WarnInGS
• Danger of explosion if batteries are incorrectly replaced. Replace only with the same
or equivalent type.
• Be sure to install the batteries before unplugging the AC adapter.
• When the unit is going to be left unplugged for a long time, remove the batteries to
avoid undue battery discharge and unit damage from battery leakage.
• Do not dispose of battery in a fire; battery may explode or leak.
• Do not mix old and new batteries. Do not mix ALKALINE, standard (CARBON-ZINC)
or rechargeable (NICKEL-CADMIUM) batteries.
When to replace the Batteries
To check the batteries' condition, If the playback is abnormal, replace the batteries with
new ones.
caUtIOn: When discarding batteries, environmental problems must be considered
and local rules or laws governing the disposal of these bateries must be strictly
followed.
removing the ipod Dock adapter
1. Remove the iPod Dock Adapter as illustrated
in the figure to the right.
2. Replace it with another one if desired.
your responsibility
(1) You must retain your bill of sale to provide proof of purchase.
(2) These warranties are effective only if the product is purchased and operated in the U.S.A.
or Canada.
(3) Warranties extend only to defects in material or workmanship, and do not extend to
any product or parts which have been lost or discarded, or damage to product or parts
caused by misuse, accident, improper operation or maintenance, or use in violation of
instructions provided with the product, or to product which has been altered or modified
without authorization of aVc, or to products or parts thereof which have had the serial
number removed or changed.
In the event your product requires repair after the limited warranty period has expired, please
contact our Customer Support Center at 1-800-506-5746, 1-877-252-6873 or
www.rcaav.com
Hours: Monday-Thursday: 9am-7pm, Friday: 9am-5pm, Saturday: 9am-NOON Eastern time.
Important:
You are responsible for any transportation, shipping or insurance relative to the return of the
product to our Product Returns Center.
aVc mULtImeDIa ("aVc") makes the following limited warranty. These limited warranties
extend to the original consumer purchaser and is limited to non-commercial user of the
product.
One year parts & Labor Warranty
AVC products purchased in the United States are warranted to be free from defects in
materials or workmanship for a period of one year from the date of their original retail
purchase. If the unit fails to conform to this warranty, we will service the product using new or
refurbished parts and products, at aVc's sole discretion.
During a period of one year from the effective warranty date, aVc will provide, when needed,
service labor to repair a manufacturing defect at its designated Service Center. To obtain
warranty service in the United States, you must first call our customer Support center
at 1-800-506-5746 or 1-877-252-6873, during the hours listed in the box below. The
deternination of service will be made by AVC customer support.
pLeaSe DO nOt retUrn yOUr UnIt tO aVc WItHOUt prIOr aUtHOrIZatIOn. New
or remanufactured replacements for defective parts or products will be used for repairs by
aVc at its designated Service Center for one year from the defective warranty date. Such
replacement parts or products are warranted for an additional one year from the date of
repair or replacement. The Customer will be required to ship the unit to the Service Center
indicated at the time Customer Support is contacted to make the necessary repairs. The
customer is responsible for all transportation charges to the service facility.
packaging and Shipping Instruction
When you send the product to the aVc service facility you must use the original carton box
and packing material or an equivalent as designated by aVc.
All warranties implied by state law, including the implied warranties of merchantability and
fitness for a particular purpose, are expressly limited to the duration of the limited warranties
set forth above. With the exception of any warranties implied by state law as hereby limited,
the foregoing warranty is exclusive and in lieu of all other warranties, guarantees, agreements
and similar obligations of manufacturer or seller with respect to the repair or replacement of
any parts. In no event shall aVc be liable for consequential or incidental damages.
No person, agent, distributor, dealer or company is authorized to change, modify or extend
the terms of these warranties in any manner whatsoever. The time within action must be
commenced to enforce any obligation of aVc arising under the warranty or under any
statute, or law of the United States or any state thereof, is hereby limited to one year from the
date of purchase. This limitation does not apply to implied warranties arising under state law.
This warranty gives you specific legal rights and you may also have other rights, which
may vary from state to state. Some states do not allow limitation on how long an implied
warranty lasts, when an action may be brought, or the exclusion or limitation of incidental or
consequential damages, so the above provisions may not apply to you.
For more information on other products and services, please contact our web site at www.rcaav.com
Important: Also keep your “Bill of Sale” as proof of purchase.
Model no. .......................................................................... Product name .............................................................
Type of set .....................................................................................................................................................................
Serial no. ............................................................................ Invoice no. .................................................................
Date purchased ............................................................... Dealer name ...............................................................
FOR SERVICE AND REPAIR, PLEASE VISIT
www. rcaav.com
Out of Warranty
Printed in China
811-833891W011
Need More Help?
Please visit online help at http: //www.rcaav.com
