RedMax CHT2250 User Manual
Page 57
P/L-3
CHT2250
Fig.1 CUTTER GROUP CHT2250
12. Parts list
Key#
Part Number
Description
Q'ty Note
1
T4002-31110
Gear case
1
2
T4002-31210
Cover
1
3
T4002-31220
Gasket
1
4
3884-11410
Drum
1
5
06004-06001
Bearing
2
6
T4001-31320
Snap ring
1
7
T4001-31330
Pinion
1
8
T4001-31340
Bearing
2
9
T4001-31350
Gear comp.
1
10
T4001-31510
Rod
2
11
04064-02512
Snap ring
1
12
3199-13350
Fitting
1
13
T4001-31360
Felt
1
14
T4001-31370
Bolt, M5x12
7
15
T4002-32110
Guide plate
1
16
T4002-32210
Blade
2
17
3884-11750
Screw (L:19)
4
18
3880-11780
Washer
4
19
3880-11790
Nut
4
20
T4001-32310
Screw, M5x16
2
21
T4001-32320
Nut
2
22
T4002-32910
Cover, blade
1
23
T4002-33110
Handle (Front)
1
24
0225-10635
Bolt
2
25
0280-10605
Nut
2
26
6845-13100
Handle (Rear) Assy
1
27
6845-13130
• Switch
1
28
3873-13140
• Pin
1
29
3873-13150
• Spring
1
30
3873-13160
• Cap
1
31
3873-13170
• Plate
1
32
3873-13180
• Screw
1
33
3873-13210
• Wire end
1
34
3873-13221
• Lever
1
35
3873-13230
• Snap ring
1
36
6845-13310
• Stopper
1
37
6845-13320
• Spring
1
38
3873-13240
• Screw
5
39
3873-13250
• Screw
1
40
0280-10403
• Nut
6
41
0225-50650
Bolt
1
42
0280-10605
Nut
1
43
0225-50640
Bolt
1
44
0225-10614
Bolt
2
45
1111-91003
Tool set
1
46
3540-91120
Spanner
1
47
1110-91320
Socket
1
48
1030-91340
Driver
1
49
T4001-39120
LABEL
1
Key#
Part Number
Description
Q'ty Note
50
848-D14-90G0
LABEL
1
101
3880-95020
Wrench
1
OP
102
3880-95010
Wrench
1
OP
