Installation
40 Runco VX-22d Installation/Operation Manual
PRE
L
IMINAR
Y
3.10
Primary Lens
Adjustments To access the motorized lens controls, use the FOCUS, ZOOM and LENS buttons on the
VX-22d remote control unit (described on page 14).
Alternatively, select Display Device from the Service Menu. Select Configure, then Lens
from the Display Device menu. The Lens menu gives you a great deal of control over the
picture size, position and focus:
Focus To focus the projected image, use the cursor buttons to highlight “In” or “Out.” Then,
press and hold the ENTER button on the remote control.
Zoom To make the picture smaller (zoom out), use the cursor buttons to highlight the minus sign
(-). Then, press and hold the ENTER button on the remote control.
To enlarge the picture (zoom in), use the cursor buttons to highlight the plus sign (+).
Then, press and hold the ENTER button on the remote control.
Vertical and Horizontal
Lens Shift
To change the projected image position, use the cursor buttons to highlight “Left,”
“Right,” “Up” or “Down” in the Lens menu. Then, press and hold the ENTER button to
shift the image in that direction.
➤
➤
➤
