9. SPECIFICATIONS
- 18 -
MODEL EH025A
Starting System Recoil starter
Type
Air-Cooled, 4-Stroke, Single Cylinder, Overhead valve,
Gasoline Engine
Fuel Tank Capacity 0.5 L
Bore x Stroke
1.34 in. x 1.06 in.
(34 mm x 27 mm)
Carburetor Diaphragm type
Displacement 1.49 cu. in. (24.5 cm 3 )
Valve Clearance
(Intake & Exhaust) 0.0059 in. (0.15 mm)
Note : Adjust the valve clearance while the engine is cold.
Emissions Durability
Period
(California only)
300 hours
Maximum Output 0.81kW (1.1 HP) / 7000 rpm
Maximum Torque 1.18 N m (0.12 kgf m)/ 5000 rpm
Direction of Rotation Counterclockwise as viewed from P.T.O. shaft side
Lubricant
Automobile Engine Oil SAE #20, #30 or 10W-30 ;
Class SF or higher grade
Capacity of Lubricant 80 mL
Fuel Automotive unleaded gasoline
Spark plug NGK CMR6A (M10 xP1.0)
Dry Weight 6.17 lb. (2.8 kg)
Dimension (L x W x H)
6.50 in. x 8.39 in. x 8.86 in.
(165 mm x 213 mm x 225 mm)
EH035A
1.54 in. x 1.10 in.
(39 mm x 28 mm)
2.04 cu. in. (33.5 cm 3 )
1.18kW (1.6 HP) / 7000 rpm
1.76 N m (0.18 kgf m)/ 5000 rpm
100 mL
Fuel Consumption Ratio
At Continuous Rated Output
408 g/kw h (300g/HP h) 340 g/kw h (250g/HP h)
0.65 L
7.72 lb. (3.5 kg)
7.52 in. x 9.21 in. x 9.72 in.
(191 mm x 234 mm x 247 mm)
Emissions Compliance Period
(Except the State of California)
For handheld engines : The Emissions Compliance Period referred
to on the Emissions Compliance label indicates the number of
operating hours for which the engine has been shown to meet
Federal emission requiremants.
Category C=50 hours, B=125 hours, and A=300 hours.
