RocketFish QS2-T User Manual

Qs2-t car speakerphone, Quick setup guide, Rf-qs2-t

background image

Indicator

Volume down
Power/Send/End
button

Microphone

Volume up

Visor clip

Charger

connector

QUICK SETUP GUIDE

QS2-T Car Speakerphone

RF-QS2-T

Congratulations on your purchase of the RF-QS2-T
Bluetooth Speakerphone. This speakerphone enables
comfortable, hands-free communication with a
Bluetooth-compatible phone.

Package contents

• RF-QS2-T speakerphone

• Car charger adapter

• USB charging cable

Quick Setup Guide

Features

Charging the battery
Before using your speakerphone, you must charge it
for about two hours. When the battery is fully charged,
it provides up to 11 hours of talk time and up to
1,400 hours of standby time.
1 USB charging: use the USB cable to plug your QS2-T

speakerphone into a computer or other USB power
port.

2 Car charging: use the car charger adapter and USB

charging cable to charge your QS2-T speakerphone
in your car.

Turning the speakerphone on
Press and hold the Power/Send/End for about
two seconds. RF-QS2-T beeps and the yellow-green
indicator light starts blinking. (First time use requires
pressing it for 4 seconds.)

Turning the speakerphone off
Press and hold the Power/Send/End for about
four seconds, RF-QS2-T beeps and the red indicator light
is displayed briefly.

Pairing the speakerphone
1
Make sure that the compatible phone is turned on

and within 33 ft. (10 m) of the speakerphone.

2 Turn on the QS2-T and make sure it’s fully charged.

Press and hold the Power/Send/End button for
about four seconds. The yellow-green indicator
flashes rapidly. Release the button. The
speakerphone is now in pairing mode.

3 Activate the Bluetooth connection from the phone.

See your phone’s documentation for more
information.

4 Set the phone to start searching for Bluetooth

devices.

5 Select

RF-QS2

from the list.

6 Enter

the

PIN

0000 to connect (or “pair”) the

speakerphone to the phone. The speakerphone
beeps once, and the indicator blinks yellow-green to
indicate the Bluetooth connection is active.

To... Do

this...

Make a call

Press Power/Send/End.

Redial Double-press

Power/Send/End.

Answer a call

Press Power/Send/End.

End a call

Press Power/Send/End.

Refuse a call

Double-press Power/Send/End.

Change the speaker

Press the volume up button (+) to increase

volume

volume or press the volume down (-) button to

decrease.

Mute or unmute a call

Press and hold the Volume down (-) button until

a tone is heard.

Switch a call between

Press and hold Power/Send/End for

the phone and the

two seconds.

speakerphone

Voice dialing
When no call is in progress, quickly press and release
Power/Send/End. When you hear a tone, speak the
number or voice tag for the number you want to call.
(The phone must have a voice dial feature and have
recorded voice tags.)

Making a call

Turning the indicator on or off

Press the power and volume up buttons at the same
time for about four seconds. The indicator turns on.
Press the power and volume down buttons at the
same time for about four seconds. The indicator
turns off. You can enable or disable the indicator
when the speakerphone is connected with your
phone.

Disconnecting the speakerphone from the phone
To disconnect the speakerphone from the phone, do
one of the following:

Turn off the speakerphone.

Disconnect the RF-QS2-T in the phone’s menu.

Move the speakerphone more than 33 ft. (10 m)
away from the phone.

Note: You do not need to delete the pairing to
disconnect the speakerphone. When you reconnect a
paired speakerphone, you will not be asked for its PIN
again.
If you want to pair your speakerphone with new phones,
you don’t need to erase all paired device information.
There can be up to eight different paired devices
information stored.

To erase paired devices from your speakerphone:

When the speakerphone turned off, press and hold
the Power/Send/End and volume up (+) buttons
simultaneously for more than six seconds. A tone
plays, and the indicator flashes red and yellow-green.
The speakerphone then enters the pairing state
automatically.
