Rockford Fosgate bd1000.1 - Manual (Page 4)

1
Specifications
*recommended fuse not supplied
System Model bd500.1 bd1000.1 bd1500.1
Frequency Response: 10-250Hz ± 3dB 10-250Hz ± 3dB 10-250Hz ± 3dB
Bandwidth:
10-250Hz ± 3dB 10-250Hz ± 3dB 10-250Hz ± 3dB
Input Sensitivity: 125mV to 2.8V 125mV to 2.8V 125mV to 2.8V
Protection:
Over - current protection
Battery under - over voltage protection
Thermal protection
Battery Fuse: 50 Amperes 100 Amperes 150 Amperes
Input Impedance:
20k
Ω
20k
Ω
20k
Ω
Number of Channels: Mono Amplifier <1% THD + N
RMS Continuous Power:
400W into 4
Ω
500W into 4
Ω
750W into 4
Ω
with <1% THD with <1% THD with <1% THD
600W into 2
Ω
1000W into 2
Ω
1500W into 2
Ω
with <1% THD with <1% THD with <1% THD
Signal to Noise Ratio:
90dB A-weighted
Crossover Slope:
24dB/octave Butterworth
Crossover Frequency Range: 50 to 250Hz
Recommended Fuse:
50amps* 100amps* 150amps*
