10
S
PECIFICATIONS
Specifications subject to change without notice
MODEL PUNCH X150.1
Peak Power Rating - Measured at 14.4 Volts
Mono into a 2 Ω Load 400 Watts
Dynamic Power Rating (IHF-202 Standard) - Measured at 14.4 Volts
Mono into a 4 Ω Load 110 Watts
Mono into a 2 Ω Load 190 Watts
Continuous Power Rating (Competition Standard) - Measured at 13.8 Battery Volts
RMS continuous power mono, driven into a 75 Watts
4 Ω load from 20 to 20,000Hz with less than
0.05% Total Harmonic Distortion (THD)
RMS continuous power mono, driven into a 150 Watts
2 Ω load from 20 to 20,000Hz, with less than
0.1% Total Harmonic Distortion (THD)
Signal-to-Noise Ratio >100dB A-weighted
Crossover Slope 24dB/octave Butterworth
Crossover Frequency variable from 50Hz to 250Hz
Dimensions 2.60" (6.60cm) H
9.60" (24.38cm) W
6.70" (17.01cm) L
Frequency Response 20Hz to 20kHz ±0.5dB
Bandwidth 10Hz to 200kHz ±3dB
Damping Factor @ 4 Ω (at output connector ) >200
Slew Rate 30 Volts/ms
IM Distortion (IHF) <0.05%
Source Unit Compatibility (+15dB gain overlap) 17V max. (low level in)
Input Sensitivity (+0dB gain overlap) Variable from 250mV to 4V (low level in)
Variable from 650mV to 11V (high level in)
Protection NOMAD - Internal analog-computer output protection
circuitry limits power in case of overload. Thermal
switch shuts down the amplifier in case of overheating.
Battery Fusing Rates (External to Amplifier) 15 amps
Fuse Type ATC
Equalization (45Hz Punch Bass) Variable from 0dB to +18dB @ 45Hz
Input Impedance 20k ohms
