25
SPECIFICATIONS
RECEIVER
Frequency Coverage ............ 26.965 to 27.405 MHz
Sensitivity....................................... 0.5 mV for 10 dB
(S+N)/N Adjacent Channel Rejection ............. 60 dB
Squelch .................................. Adjustable from 1 mV
Audio Output ............................ 400 mW (10% THD)
Current Drain
Standby .................................................. 55 mA
Receive ................................................ 550 mA
Note: The transceiver draws an additional 800
mA when charging nickel-cadmium batteries.
TRANSMITTER
Frequency Coverage ............ 26.965 to 27.405 MHz
Power Input ....................................... 5 W (at HIGH)
2.5 W (at LOW)
Power Output ................................... 3.8W (at HIGH)
0.8 W (at LOW)
Conducted Spurious
Emission Harmonics ......................... 60 dB or better
Type of Modulation .............................................. A3
Frequency Tolerance ................................... 0.002%
Antenna Impedance .................................... 50 Ohm
Current Drain
HIGH ........................................................ 1.6 A
LOW ..................................................... 600 mA
Note: The transceiver draws an additional 800
mA when charging nickel-cadmium batteries.
Dimensions (HWD) ........... 2 1 / 8 ¥ 6 13 / 16 ¥ 1 3 / 4 Inches
(54 ¥ 172.5 ¥ 45 mm)
Weight ................................................. 11 oz (318 g)
Specifications are typical; individual units might vary.
Specifications are subject to change and improve-
ment without notice.
