Rockford Fosgate P162S - Manual (Page 9)

9
S
PECIFICATIONS
Specifications subject to change without notice
System Crossover Dimensions FEATURES - System Crossover
Crossover Frequency
3200Hz @ 4
Crossover Slope 12dB/octave High-Pass
12dB/octave Low-Pass
Filter Q Butterworth
Tweeter Protection Optical Compression
System Model P152S P162S
Nominal Diameter - inch (mm) 5-1/4 (133) 6-1/2 (165)
Nominal Impedance (ohms) 4 4
Frequency Response 70Hz-22kH 60Hz-22kHz
Sensitivity (SPL@1w/1m) 86dB 88dB
Power Handling(Watts RMS/Peak) 60 / 120 60 / 120
Mounting Diameter - inch (mm) 4-1/2 (117) 5-1/2 (141.6)
Mounting Depth - inch (mm) 2-1/2 (50.4) 3 (74.1)
FEATURES
• Mica Injected Polypropylene Cone
• Cold Rolled Vented Steel Frame
• Polyurethane Surround
• Multiple Tweeter Mounting Configurations
