Catalog No.: 4000.22C Effective:03-15-08 Replaces: 12-28-07
HOT WATER STORAGE TANKS
ASME CODE
CUSTOM
115 TO 2590 GALLONS
For larger tanks contact factory
FEATURES
• 125 PSI pressure rating (Standard)
150 PSI pressure rating available
• Vertical (150 PSI optional) or horizontal
• Manhole
• Angle iron legs on vertical tanks
• Saddles available on horizontal tanks
• Available openings in:
Threaded
Flanged
Stainless steel
• Optional double glass lining
• Available linings:
Glass
Epoxy
Cement
• National Board stamped
• Magnesium anodes (Glass lined tanks only)
• Lifting lugs
Horizontal tank
Vertical tank
FOR STOCK ASME CODE TANKS SEE CATALOG NO.
4000.20.1 80-115 GALLONS
4000.21 175 GALLONS
4000.10 235-534 GALLONS
