7
• SOUND ADJUSTMENT
Press SEL button (10) to select the desired adjustment mode.
The adjustment mode will change in the following order:
By pressing VOL button (11) or VOL button (12), it is possible to adjust the
desired sound quality.
• LOUDNESS
Press BND/LOU button (13) for several seconds to reinforce the bass output and
display will show “LOUD”. Press it for several seconds again to release this
function.
• SET THE CLOCK
Holding down the DSP button (15) until the clock is shown on the LCD display and
flashed. Then press the TUNE/SEEK/TRACK button (17) to change hours or
TUNE/SEEK/TRACK button (16) to change minutes.
• SELECT MODE
Press MOD button (6) to choose desired listening mode.
(e.g. radio mode to CD mode)
• MUTE
Press MUT button (3) to silence the receiver. Press it again to resume listening.
• LIQUID CRYSTAL DISPLAY
Exhibit current frequency and activated functions on the display (8).
• EQUALIZATION
Press EQ button (19) to turn on equalization function and to select desired audio
mode. There are five kinds of mode as below:
• FLASHING LED
If the front panel does not install in the unit, the LED (24) will be flashing.
• RESET
RESET button (25) must be activated with either a ball point pen or thin metal
object. RESET button (25) is to be activated for the following reasons:
- Initial installation of the unit when all wiring is completed.
- All the function buttons do not operate.
- Error symbol on the display.
Note: If press RESET button (25), the unit can’t work yet, please use a cotton swab
soaked in isopropyl alcohol to clean the socket on the back of the front panel.
FLAT CLASSICS POP M ROCK M DSP OFF
Volume Bass Treble Balance Fader
