9
VIEWS
Top / Bottom View
5. Sleep/Wake up Button Press and hold Sleep/Wake up button for about two
seconds to Wake up the unit.
6. USB Interface Interface for connecting to a PC by means of the
ActiveSync Cable (for data matching).
Left / Right View
7. External Aerial Interface Interface for an optional second aerial.
8. Volume+/-
Switch Volume+/- to adjust the volume level.
9. Battery On/Off Switch Switch it to Lock/Unlock position to turn the power
On/Off.
10. SD/MMC Slot Accepts an optional SD (Secure Digital) or MMC
(Multi MediaCard) Card for removable storage.
11. Headphone Interface Connects to a pair of stereo headphones.
12. AC Adaptor Port
Connection to external power supply.
10
11
12
5
6
7
8
9
