CONNECTORS & INDICATORS:
RF Output: SMA connector epoxied to straight feed point
antenna in compliance with FCC rules part 15C, 15.203.
Specifications
Video: BNC female bulkhead mount
Audio1/2: RCA female bulkhead mount
Controls: Channel switch – momentary, toggles through modes/channels
Indicators: 8 channel LEDs that blink slowly in Standby mode
ENVIRONMENTAL:
Operating Temp.: -20 to 70 ºC
Storage: -30 to 85 ºC
Humidity: 95% noncondensing
Powerup
At powerup, the unit will retrieve the last used channel, program the PLL with this channel, and display the
channel by blinking the LED the same number as the channel number.
Displaying Current Channel
To display the current channel, press the pushbutton once and release. The current channel will blink.
After approx. 5 seconds, the current channel will again blink
.
Changing to a New Channel
To change to a new channel, press the pushbutton once and release. The current channel will blink. Press
and release the pushbutton again before 5 seconds has elapsed and the channel will increment by 1 and the
LED will blink the new channel. Repeat this step until the desired channel is reached, waiting for the
blinking to stop each time before pressing the button again.
Once your desired channel is reached, wait 5 seconds until the LED again blinks your desired channel.
Your new channel is now saved in memory.
8 CHANNELS ARE AVAILABLE IN 2.4 GHz RANGE.
www.rf-links.com
Copyright © 2000-2006 rf-links.com All Rights Reserved
NOTE:
Model
XL-2000/2 HAS 2 W RF POWER OUTPUT.
Model XL-2000/H HAS 5 W RF POWER OUTPUT.
Model XL-2000/HP HAS 10 W RF POWER OUTPUT
Note:
RECEIVER HAS 8 MATCHING CHANNELS, CHANNEL SETTINGS FOR THE RECEIVER IS
INTERNAL.
