Page.6
Attaching Speaker Cables
When.using.a.banana.jack.to.attach.
speaker.cables.to.the.binding.post.
terminals,.insert.the.speaker.cables.
into.the.banana.jack..Next.insert.the.
banana.jack.into.the.hole.provided.in.
the.top.of.the.terminal..Repeat.for.the.
other.speaker.cable(s).as.necessary.
If.not.using.a.banana.jack,.simply.
loosen.the.binding.nut.to.allow.the.
hole.in.the.side.of.the.terminal.to.
become.exposed..Strip.¼-inch.of.
the.insulation.from.the.end.of.the.
speaker.cable.and.insert.the.exposed.
wire.end.into.the.now.exposed.hole.
in.the.side.of.the.terminal..Tighten.
the.binding.nut.by.turning.the.nut.
clockwise.until.the.speaker.cable.
is.secured..Repeat.for.the.other.
speaker.cable(s).as.necessary.
Standard.Wiring.Diagram
Bi-amplifying.Wiring.Diagram
NOTE:.Connecting.
strapes.must.be.
removed.before..
bi-amping.or..
bi-wiring.
Attaching.Speaker.Cables
To.Tweeters.
and.Mid-range.
To.Woofers.
