10
OPERATION
The dust bowl should be checked, emptied and cleaned
periodically to obtain maximum dust collection.
TO REMOVE DUST BOWL
See Figure 8.
■ Depress the release button located on top of hand
vac. Pull dust bowl down and out as shown to sepa-
rate from motor housing.
CLEANING YOUR HAND VAC
See Figures 5, 6 and 7.
WARNING:
Never use your hand vac without dust bowl and filter
properly in place.
■ Remove the filter by simply pulling it out of dust bowl.
See Figure 9.
■ Shake or lightly brush any dust or dirt off filter.
■ Empty dust bowl and wash if necessary. Make sure
dust bowl is completely dry before reattaching to hand
vac.
TO REATTACH DUST BOWL
See Figure 10.
■ Position the two sections as shown. Align slots on
bottom of dust bowl with tabs on bottom of motor
housing then snap the two sections together.
Fig. 8
Fig. 9
Fig. 10
TABS
PRESS RELEASE BUTTON
PULL DUST BOWL
DOWN AND OUT
TO REMOVE
FILTER
DUST BOWL
HAND VAC
BATTERY PACK
SLOTS
