Roksan Audio ltd Caspian Integrated Amplifier User Manual
CLASSIFICATION: General Use Version 3.07
All specifications are liable to change without notice. E&OE Page 11 ENGLISH
Line Inputs 5 plus Tape
Input Impedance 47 k Ω
Input
Sensitivity (80W) Line 240mV
Line Outputs Tape, Preamplifier (x2)
Output Voltage 240mV (Tape Out)
700mV (Pre Out)
Power Outputs Loudspeaker, L & R
Output Power 85 Watts continuous, into 8 Ω
both channels driven
120 Watts continuous, into 4 Ω
both channels driven
Power Supply 350VA Ultra Low Noise Toroidal Transformer
4 Regulated Supply Rails
Current Output 50 Amps Peak to Peak
Damping Factor >140 (8 Ω)
Frequency response -3dB, 1Hz – >100kHz
Gain 40dB Overall (Pre & Power)
9.3dB Preamplifier
30.7dB Power Amplifier
Harmonic Distortion <0.003% 1kHz - 8 Ω
<0.003% 1kHz - 4 Ω
Signal to Noise Ratio Line 108dBa (ref 500mV)
85dBa (ref 1W, 8 Ω)
Power Source 100V – 120V 50Hz / 60Hz
220V – 240V 50Hz / 60Hz
(via filtered mains inlet)
Power Consumption < 230 W
Dimension 432 x 330 x 70 (W x D x H) mm
432 x 330 x 80 (including feet)
Weight 13 Kg
S P E C I F I C A T I O N S C a s p i a n Integrated Amplifier
