EBZ5000Q
Fig.1 BLOWER GROUP
(S/N 300001 and up)
Key#
Part Number
Description
Q'ty
1 848-L3H-55A0
VOLUTE CASE
1
2 848-L3H-55B1
VOLUTE COVER
1
3
T4970-52510
SCREW
10
4
T4970-52510
SCREW
3
5
T4030-31410
ELBOW
1
6
07000-02095
O-RING
1
7
T4960-57030
SCREW
2
8
3310-53331
NUT
2
9
T4017-31310
FUNNEL
1
10 848-8K4-0010
CLAMP
1
11
T4970-51410
SCREW
1
12
2750-31290
TUBE
1
13
T4017-31510
FAN
1
14
848-816-3500
BOLT
4
15
T4017-31600
ENGINE COVER ASSY
1
16
T4017-31620
GLASS WOOL
1
17
T4970-50831
SCREW
4
18
T4970-52510
SCREW
5
19
T4017-32100
FLAME COMP.
1
20
3490-21121
• RING
2
21
2756-32310
BAND (A)
2
22
T4017-32320
BAND (B)
2
24
T4017-21310
PAD
1
25
3495-21320
CLIP
5
26
T4017-32500
NET COMP.
1
27
1480-74710
CLIP
4
28
T4017-32600
PLATE
1
29
T4970-50831
SCREW
7
30
2750-32510
DAMPER, UPPER
1
31
848-870-5030
WASHER
1
32
T4972-54010
SCREW
1
33
T4960-51631
SCREW
2
34
2750-32610
DAMPER, LOWER
2
35
2750-32620
NUT
2
36 848-L3B-8500
TANK ASSY
1
37
T1015-85202
• CAP ASSY
1
38
4500-85300
• • HOLDER ASSY
1
39
4500-85220
• • PACKING
1
40
5601-85260
• • FILTER
1
41
4820-85260
• • STOPPER
1
42
2750-85300
• PIPE COMP.
1
43
3302-85400
• FILTER
1
44
1260-85460
• CLIP
1
45
T4960-51231
SCREW
2
46
1950-86120
CLIP
1
47
2750-31911
LABEL, CAUTION
1
48
T4012-32610
LABEL, NET
1
49
T4017-51341
LABEL, SILENCER
1
50 848-L3D-90J0
LABEL, NOISE
1
Key#
Part Number
Description
Q'ty
51
T4030-51110
HOSE
1
52
2750-51201
SWIVEL JOINT
1
53
T4017-51300
PIPE, SILENCER
1
54
6811-51220
PIPE, END
1
56
T4030-51510
CLAMP
1
57
2756-51520
CLAMP
1
58
T4017-91000
TOOL SET
1
59
3540-91120
• SPANNER
1
60
T4017-91130
• SOCKET
1
