9
Troubleshooting
Most difficulties in audio systems are the re-
sult of incorrect connections, or improper
control settings. If you encounter problems,
isolate the area of the difficulty, check the con-
trol settings, determine the cause of the fault
and make the necessary changes. If you are
unable to get sound from the RCD-961, re-
fer to the suggestions for the following con-
ditions:
Power Indicator Is Not Lit
The Power Indicator and the basic items in
the Display window should be lit whenever
the RCD-961 is plugged into the wall power
outlet and the Power button is pushed in. If it
does not light, test the power outlet with an-
other electrical device, such as a lamp. Be sure
the power outlet being used is not controlled
by a switch that has been turned off.
Specifications
Total Harmonic Distortion + Noise 0.0045% @ 1kHz
Intermodulation Distortion 0.0045% @ 1kHz
Frequency Response ( ± 0.5 dB) 20-20,000 Hz
Channel Balance ± 0.5 dB
Phase Linearity ± 0.5 degree
Channel Separation > 98 dB @ 1kHz
Signal to Noise Ratio > 100dB
Dynamic Range > 96 dB
Digital to Analog Converters 18 bit equivalent, multi-level Delta-Sigma DAC with
8x oversampling digital filter and HDCD
Speed Accuracy, Wow & Flutter Quartz Crystal Precision
Output Impedance 100 Ohms
Digital Output 0.5 Volt, Peak to Peak
Load Impedance 75 Ohms
Power Requirements
USA Version AC 115V, 60 Hz
European Version: AC 230V, 50 Hz
Power Consumption 20 Watts
Dimensions (W, H, D) 17 3 / 8 x 2 7 / 8 x 12 7 / 16 inches
440 x 72 x 316 mm
Weight (net) 5.4 kg, 11.9 lb.
All specifications are accurate at the 571 -ofe sr vs nhe 5rght o Pmake imp ,verents
