PARTS LIST
The model number will be found on a plate attached to the engine housing. Always mention the model number in all correspondence regarding your
GAS PRUNER or when ordering replacement parts.
KEY PART
NO. NUMBER DESCRIPTION QTY
1 986163001 * Hex Nut (M8) ............................................................................................................................................................... 1
2 PA01333 Bar Clamp Assembly .................................................................................................................................................. 1
3 986164001 Guide Bar Adjustment Screw (M5 x 50 mm) .............................................................................................................. 1
4 986165001 * Retaining Ring (4 mm) ................................................................................................................................................ 1
5 PS04974 Guide Bar Plate ........................................................................................................................................................... 1
6 986185001 Guide Bar Adjusting Pin .............................................................................................................................................. 1
7 986162001 * E-ring (6 mm) .............................................................................................................................................................. 2
8 04939A Cupped Washer .......................................................................................................................................................... 1
9 985224001 Sprocket ..................................................................................................................................................................... 1
10 PS03873 Chain (3/8, .043, 10) .................................................................................................................................................... 1
11 983872002 Guide Bar .................................................................................................................................................................... 1
12 PS04554 Bar Pad Plate .............................................................................................................................................................. 1
13 986166001 Oil Pump Seal Assembly ............................................................................................................................................ 1
14 985221001 Oil Pinion Gear & Plunger ........................................................................................................................................... 1
15 985223001 Worm Gear .................................................................................................................................................................. 1
16 986160001 Oil Pump Housing w/Cam Pin Assembly ................................................................................................................... 1
17 986161001 * Screw (M5 x 3 mm) ..................................................................................................................................................... 2
18 A07591 Oil Cap with Retainer (Pkg.) ........................................................................................................................................ 1
19 985895001 * Screw (M5 x 18 mm) ................................................................................................................................................... 4
20 985896001 Oil Tank Cover Assembly ............................................................................................................................................ 1
21 985265001 Oil Cover Gasket ......................................................................................................................................................... 1
22 986155001 * Screw (M5 x 25 mm, Shoulder Screw) ....................................................................................................................... 3
23 986158001 * Screw (M5 x 25 mm) ................................................................................................................................................... 1
24 PS05449 * Screw (10-24 x 5/8 in. Hex Washer Hd. Tri-Lobular) .................................................................................................. 1
25 090038001042 Gear Case & Cover Assembly .................................................................................................................................... 1
26 985252001 Pinion Gear Assembly ................................................................................................................................................ 1
27 985262001 Wavy Washer .............................................................................................................................................................. 1
28 PA01487 Pick-Up Tube Assembly ............................................................................................................................................. 1
29 985253001 Output Shaft Assembly ............................................................................................................................................... 1
30 983606001 Blade Cover ................................................................................................................................................................ 1
31 985165001 Expand-it Label ........................................................................................................................................................... 1
32 986173001 Warning Label ............................................................................................................................................................. 1
33 986186001 Pruner Boom Assembly (55 in.) (Includes Key. Nos. 31 and 32) ................................................................................ 1
34 986172001 Pruner Gear Head (Includes Key. Nos. 1-9 and 12-30) .............................................................................................. 1
RYOBI TP30 GAS PRUNER
MODEL NO. RY52004A
* STANDARD HARDWARE ITEM — MAY BE PURCHASED LOCALLY
