Using the AC adaptor

The AC adaptor for use with the Ecologic 3 should provide 7.5 volts
DC output at 800mA centre pin positive.

1. Insert the adaptor plug into the DC IN socket on the left hand side of

your radio.

2. Plug the adaptor into a standard 13A mains socket outlet. Whenever

the adaptor is used the batteries are automatically disconnected.

The AC adaptor should be disconnected from the mains supply and
the radio when not in use.

• IMPORTANT:

The mains adaptor is used as the means of connecting

the radio to the mains supply. The mains socket used

for the radio must remain accessible during normal use. In order

to disconnect the radio from the mains completely, the mains

adaptor should be removed from the mains socket outlet

completely.

DC 7.5V 800mA

5
