9 — English
 For trimming, adjust the handle upward.
 For edging, adjust the handle downward.
 Turn the knob clockwise until the handle is securely
tightened before reinstalling the battery pack.
ThREE-posITIoN pIVoTINg hEAD
See Figure 8.
The trimmer head can be adjusted to three different
positions.
 Remove the battery pack.
 Depress the pivot button and move the trimmer head up
or down to one of the three positions indicated by the
notches.
NoTE: Adjust the trimmer head to the first and second
notches for trimming and edging. Adjust to the third notch
for storage only.
 Make sure the trimmer head is securely locked into place
before reinstalling the battery pack.
opERATINg ThE TRIMMER
See Figure 9.
Follow these tips when using the string trimmer:
 Hold the trimmer with your right hand on the rear handle
and your left hand on the front handle.
 Keep a firm grip with both hands while in operation.
 Trimmer should be held at a comfortable position with the
rear handle about hip height.
 Cut tall grass from the top down. This will prevent grass
from wrapping around the shaft housing and string head
which may cause damage from overheating.
If grass becomes wrapped around the string head:
 Remove the battery pack from the trimmer.
 Remove the grass.
WARNINg:
Always hold the string trimmer away from the body
keeping clearance between the body and the string
trimmer. Any contact with the string trimmer cutting head
while operating can result in serious personal injury.
CUTTINg TIps
See Figure 10.
 Keep the trimmer tilted toward the area being cut; this is
the best cutting area.
 The string trimmer cuts when passing the unit from left
to right. This will avoid throwing debris at the operator.
Avoid cutting in the dangerous area shown in figure 10.
 Use the tip of the string to do the cutting; do not force
string head into uncut grass.
opERATIoN
 Wire and picket fences cause extra string wear, even
breakage. Stone and brick walls, curbs, and wood may
wear string rapidly.
 Avoid trees and shrubs. Tree bark, wood moldings, siding,
and fence posts can easily be damaged by the string.
ADVANCINg sTRINg
NoTE: The trimmer is equipped with an auto-feed head.
Bumping the head to try to advance the line will damage
the trimmer and void the warranty.
 With the trimmer running, release the switch trigger.
 Wait two seconds, and press the switch trigger.
NoTE: The string will extend approximately 1/4 in. with
each stop and start of the switch trigger until the string
reaches the length of the grass deflector cut-off blade.
 Resume trimming.
ADVANCINg ThE sTRINg MANUAlly
See Figure 11.
 Remove the battery pack.
 Push the black button located on the string head while
pulling on string to manually advance the string.
CUT-oFF blADE
See Figure 12.
This trimmer is equipped with a cut-off blade on the grass
deflector. For best cutting, advance string until it is trimmed
to length by the cut-off blade. Advance string whenever you
hear the engine running faster than normal, or when trimming
efficiency diminishes. This will maintain best performance
and keep string long enough to advance properly.
RoTATINg REAR hANDlE
See Figure 13.
The rotating rear handle is used in combination with the
edger guide.
 Remove the battery pack.
 Pull up on the edging coupler and turn handle end coun-
terclockwise until the edging coupler locks into place.
 Release the edging coupler.
EDgINg
See Figures 12 - 14.
Rotate the rear handle when using the edger guide for edging
sidewalks and walkways. To use the edger guide, flip down
from its stored position.
Always hold the string trimmer away from the body keeping
clearance between the body and the string trimmer. Any
contact with the string trimmer cutting head while operating
can result in serious personal injury.
