15
Main Specifications
● Rated Power Output
200 W (Main Unit 100 W + Satellite Speaker 50W x 2)
● Nominal Input Level (1 kHz)
INPUT
CHANNEL1 (V-DRUMS): -10–+4 dBu
(LINE IN): -20–+4 dBu
CHANNEL2 (LINE IN): -10–+4 dBu
CHANNEL3 (LINE IN): -10–+4 dBu
● Nominal Output Level
LINE OUT: +4 dBu
SPEAKER OUT: 50 W / 4 Ω
● Speakers
Main Unit: 30 cm (12 inches) x 1 (Woofer)
7.7 cm (3-1/16 inches) x 1 (Tweeter)
Satellite Speaker: 10 cm (4 inches) x 2 (Full Range)
● Controls
PUNCH Switch
Volume Knob
VOLUME Knob
VOLUME Knob
Mode Select Switch
Volume Knob
BASS Knob (Equalizer)
MIDDLE knob (Equalizer)
TREBLE knob (Equalizer)
VOLUME Knob
POWER Switch
● Indicators
POWER
● Connectors
Main Unit
V-DRUMS INPUT Jack (stereo 1/4” phone type)
LINE IN Jack (1/4” phone type)
LINE IN Jack (1/4” phone type)
LINE IN Jack (1/4” phone type / RCA PIN type)
LINE OUT Jack (1/4” phone type)
SPEAKER OUT Jack (1/4” phone type)
PHONES Jack (stereo 1/4” phone type)
Satellite Speaker
INPUT Jack (1/4” phone type)
● Power Supply
AC 117 V, AC 230 V, AC 240 V (50 / 60 Hz)
AC 220 V (60 Hz)
● Power Consumption
63 W
● Dimensions
Main Unit: (Excluding casters)
451 (W) x 482 (D) x 482(H) mm
17-13/16 (W) x 19 (D) x 19 (H) inches
(Including casters)
451 (W) x 482 (D) x 533 (H) mm
17-13/16 (W) x 19 (D) x 21 (H) inches
Satellite Speaker: 152 (W) x 158 (D) x 209 (H) mm
6 (W) x 6-1/4 (D) x 8-1/4 (H) inches
● Weight
Main Unit: (Excluding casters)
24.3 kg / 53 lbs 10 oz
(Including casters)
25.0 kg / 55 lbs 2 oz
Satellite Speaker: 2.2 kg / 4 lbs 14 oz (for each)
● Accessories
Mount Bar x 2
Clamp x 2
Speaker Cable (3.5 m) x 2
Caster x 4
Owner’s Manual
* 0 dBu = 0.775 Vrms
In the interest of product improvement, the
specifications and/or appearance of this unit are subject
to change without prior notice.
