Replacements – Napoleon Fireplaces GDI-30N User Manual
Page 11
11
W415-0384 / D / 09.13.05
#
PART # DESCRIPTION
1
GZ552
REPLACEMENT BLOWER
2
W725-0035
NATURAL GAS VALVE
2
W725-0026
PROPANE GAS VALVE
3
W455-0019
#43 NATURAL GAS BURNER ORIFICE
3
W455-0003
#54 PROPANE GAS BURNER ORIFICE
4
W357-0001
PIEZO IGNITER
5
W680-0004
THERMOPILE
6
W680-0005
THERMOCOUPLE
7
W010-0801
NATURAL GAS PILOT ASSEMBLY
7
W010-0800
PROPANE GAS PILOT ASSEMBLY
8
W690-0002
THERMAL SENSING SWITCH
9
W660-0009
BURNER ON/OFF SWITCH
10
W135-0183
REAR LOG (#1)
11
W135-0184
LEFT MIDDLE LOG (#2)
12
W135-0185
RIGHT MIDDLE LOG (#3)
13
W135-0186
LEFT CROSSOVER LOG (#4)
14
W135-0187
MIDDLE CROSSOVER LOG (#5)
15
W135-0188
RIGHT CROSSOVER LOG (#6)
16
GL-639
LOG SET
17
W361-0016
GLOWING EMBERS
18
W010-1046
BURNER ASSEMBLY
19
W455-0070
NATURAL GAS PILOT INJECTOR
19
W455-0068
PROPANE GAS PILOT INJECTOR
20
W385-0245
NAPOLEON LOGO
21
W562-0008
GLASS GASKET
22
KB-35
VARIABLE SPEED SWITCH
23
W010-1095
GLASS
W
/ GASKET
24
W010-1042
DOOR, GLASS & GASKET ASSEMBLY
25
GDI-223
TERMINAL
1-2" & 1-3" DOUBLE PLY ALUMINUM LINER-INLET AND EXHAUST &
2-3" TO 2" REDUCER:
26
GDI-2320KT
VENT KIT 20FT
26
GDI-2325KT
VENT KIT 25FT
26
GDI-2335KT
VENT KIT 35FT
2-3" DOUBLE PLY ALUMINUM LINER-INLET AND EXHAUST:
27
GDI-320KT
VENT KIT 20FT
27
GDI-325KT
VENT KIT 25 FT
27
GDI-335KT
VENT KIT 35 FT
#
PART NO. DESCRIPTION
28
GI-1LK
BLACK UPPER & LOWER LOUVRES
28
GI-1LPB
BLACK UPPER & POLISHED BRASS LOWER LOUVRES
28
GI-1LAB
BLACK UPPER & ANTIQUE BRASS LOWER LOUVRES
28
GI-1LSS
BLACK UPPER & BRUSHED STAINLESS STEEL
LOWER LOUVRES
28
GI-1LG
GOLD PLATED UPPER & LOWER LOUVRES
29
GI-OIK
BLACK UPPER & LOWER INSET W/ POLISHED
BRASS LOWER DOOR TRIM
29
GI-OIG
GOLD PLATED UPPER & LOWER INSET
30
GI30B-KT
BAY FRONT COMPLETE WITH PULL SCREEN
31
GIB-1LK
BLACK LOUVRES
31
GIB-1LPB
POLISHED BRASS LOWER LOUVRES
31
GIB-1LAB
ANTIQUE BRASS LOWER LOUVRES
31
GIB-1LSS
BRUSHED STAINLESS STEEL LOWER LOUVRES
31
GIB-1LG
GOLD PLATED LOWER LOUVRES
32
GIB-1OIK
BLACK LOWER INSET
32
GIB-1OIG
GOLD PLATED LOWER INSETS
33
GI-900K6
6" BLACK WITH MARQUIS TRIM
33
GI-900B6
6" POLISHED BRASS WITH MARQUIS TRIM
33
GI-900AB6
6" ANIQUE BRASS WITH MARQUIS TRIM
33
GI-900SS6
6" BRUSHED STAINLESS STEEL BLACK TRIM
34
GI-909S6
6" PORCELAIN ALMOND WITH MARQUIS TRIM
34
GI-909K6
6" PORCELAIN BLACK WITH MARQUIS TRIM
34
GI-909F6
6" PORCELAIN GREEN WITH MARQUIS TRIM
35
GI-900K9
9" BLACK WITH MARQUIS TRIM
35
GI-900B9
9" POLISHED BRASS WITH MARQUIS TRIM
35
GI-900AB9
9" ANTIQUE BRASS WITH MARQUIS TRIM
35
GI-900SS9
9" BRUSHED STAINLESS STEEL WITH BLACK TRIM
36
GI-909S9
9" POCELAIN ALMOND WITH MARQUIS TRIM
36
GI-909K9
9" PORCELAIN BLACK WITH MARQUIS TRIM
36
GI-909F9
9" PORCELAIN GREEN WITH MARQUIS TRIM
37
CISK
CAST SURROUND PAINTED BLACK
37
CISKK
CAST SURROUND PORCELAIN ENAMEL BLACK
37
CISKN
CAST SURROUND PORCELAIN ENAMEL
MAJOLICA BROWN
37
CISKB
CAST SURROUND PORCELAIN ENAMEL
MAJOLICA BLUE
37
CISKF
CAST SURROUND PORCELAIN ENAMEL
MAJOLICA GREEN
38
W690-0001
MILLIVOLT THERMOSTAT
39
W660-0011B
REMOTE CONTROL - ADVANTAGE PLUS
40
GD-660
REMOTE WALL SWITCH WITH 20" WIRE
41
W660-0026
TIMER, BATTERY OPERATED
42
ANI-K
ANDIRONS - BLACK
42
ANI-G
ANDIRONS - GOLD PLATED
43
GI-798KT
DECORATIVE BRICK PANELS
44
GI-910K
6" BEVELLED FLASHING -
BLACK
45
GI-942K
TRIM FOR BEVELLED FLASHING -
BLACK
45
GI-942B
TRIM FOR BEVELLED FLASHING -
POLISHED
BRASS
46
GI-RB
RISER BOX -
PAINTED
BLACK
47* W175-0218
CONVERSION KIT -
LP
-
NG
47* W175-0216
CONVERSION KIT -
NG
-
LP
When ordering replacement parts always give the follow-
ing information:
1. M
ODEL
& S
ERIAL
N
UMBER
OF
FIREPLACE
2. I
NSTALLATION
DATE
OF
FIREPLACE
3. P
ART
N
UMBER
4. D
ESCRIPTION
OF
PART
5. F
INISH
Contact your dealer for questions concerning prices and
availability of replacement parts. Normally all parts can be
ordered through your Napoleon dealer or distributor.
REPLACEMENTS
FOR
WARRANTY
REPLACEMENT
PARTS
,
A
PHOTOCOPY
OF
THE
ORIGINAL
INVOICE
WILL
BE
REQUIRED
TO
HONOUR
THE
CLAIM
.
REPLACEMENT PARTS
ACCESSORIES:
TERMINAL KITS
VENT KITS
