2
Features and Functions
1. S-Video Connector- 4-pin miniDIN female- for connecting the cable from the video source
2. S-Video Connector- 4-pin miniDIN female- for connecting the local user's display
3. Line In- 3.5mm female stereo audio connector- for connecting the cable from the audio source (not present
in VOPEX-C5SV)
4. Line Out- 3.5mm female stereo audio connector- for connecting the local self-powered stereo speakers (not
present in VOPEX-C5SV)
5. Cat 5- RJ45 female- for connecting CAT5 cables from ST-C5SVA-R-600 Receivers
6. 5VDC- 2.0A- connection jack for the AC adapter
7. Power- Green LED- illuminates when power has been supplied to the VOPEX-C5SVA-x
8. Video Adjust- forces the VOPEX-C5SVA-x to re-adjust the video on all channels (not present in VOPEX-
C5SV)
9. S-Video Connector- 4-pin miniDIN female- for connecting the remote user's monitor
10. Cat 5- RJ45 female- for connecting CAT5 cable from the VOPEX-C5SVA-x
11. Green LED- communication indicator- blinks when there is valid communication between the VOPEX-
C5SVA-x and the ST-C5SVA-R-600 Receiver.
12. Yellow LED- power indicator- illuminates when power has been supplied to the unit
13. Audio Connector- 3.5mm female stereo audio connector- for connecting the remote speakers
14. 9VDC- 1.0A- connection jack for the AC adapter
Features and Functions
5 V D C
2 A
-
+
8
7
6
5
4
3
2
1
L i n e
O u t
L i n e
I n
C a t 5
S - V i n
S - V o u t
N T I
N E T W O R K
T E C H N O L O G I E S
I N C O R P O R A T E D
T e l : 3 3 0 - 5 6 2 - 7 0 7 0
F a x : 3 3 0 - 5 6 2 - 1 9 9 9
1 2 7 5 D a n n e r D r
A u r o r a , O H 4 4 2 0 2
w w w . n t i 1 . c o m
R
P o w e r
X T E N D E X
V
T M
V i d e o
A d j u s t
N T I
R
N e t w o r k T e c h n o l o g i e s I n c
( F r o n t V i e w )
( R e a r V i e w )
V O P E X - C 5 S V A - 8
F E A T U R E S A N D F U N C T I O N S
1
2
5
6
3
4
7
8
9
S T - C 5 S V A - R - 6 0 0 R e c e i v e r
1 3
1 1
1 0
1 2
1 4
-
+
N T I
R
N e t w o r k T e c h n o l o g i e s I n c
X T E N D E X
N
TI
R
N
et
w
or
k
Te
ch
no
lo
gi
es
In
c
X
TE
N
D
E
X
-
+
( F r o n t V i e w )
( R e a r V i e w )
