© National Instruments Corporation

B-1

FPT-1015 User Manual

B

Display Timing Mode and OSD

Supported Input Timing Modes

The FPT-1015 supports and automatically recognizes the frequencies listed
in Table B-1.

Note

Even if you use the preset timing, you may need to adjust functions such as

horizontal period, CLK-delay, and display position. The adjusted values are memorized
in every preset number.

Table B-1. Supported Input Formats

Vertical Frequencies

Resolution

56 Hz

60 Hz

70 Hz

72 Hz

75 Hz

640

× 480

—

Yes

—

Yes

Yes

720

× 400

—

—

Yes

—

—

800

× 600

Yes

Yes

—

Yes

Yes

1024

× 768

—

Yes

Yes

—

Yes
