9
Monitor MultiSync ® E
700
™ Notes
Specifications Monitor
Picture Tube Diagonal: 17 inch 90 ° deflection, 0.25 mm mask pitch,
Viewable Image Size: 15.6 inch CromaClear ™ CRT, medium-short persistence
Radius: 1210 mm phosphor, multi-layered, anti-static screen
coating, dark-tint screen, Invar Shadow
Mask and OptiClear
® screen surface.
Input Signal Video: ANALOG 0.7 Vp-p/75 Ohms
Sync: Separate sync. TTL Level
Horizontal sync. Positive/Negative
Vertical sync. Positive/Negative
Composite sync. (Positive/Negative) (TTL Level)
Display Colors Analog input: Unlimited number of Colors Depends on display card used.
Synchronization Horizontal: 31 kHz to 82 kHz Automatically
Range Vertical: 55 Hz to 120 Hz Automatically
Resolutions Supported 640 x 480 @ 60 to 120 Hz Some systems may not support
Resolution based on horizontal and 800 x 600 @ 55 to 120 Hz all modes listed.
vertical frequencies only 832 x 624 @ 55 to 120 Hz
1024 x 768 @ 55 to 100 Hz ..................... NEC cites recommended resolution at
1152 x 870 @ 55 to 89 Hz
85 Hz for optimal display performance.
1280 x 1024 @ 55 to 76 Hz
1600 x 1200 @ 55 to 65 Hz
Active Display Area Horizontal: 306 mm/12.0 inches Dependent upon signal timing used,
(Factory Setting) Vertical: 230 mm/9.1 inches and does not include border area.
Active Display Area 316 mm/12.4 inches Dependent upon signal timing used,
(Full Scan) 237 mm/9.3 inches and does not include border area.
Power Supply AC 100 – 120 V, 50/60 Hz
Current Rating 1.8A @ 100 – 120 V
Dimensions 403 mm (W) x 426 mm (H) x 453 mm (D)
15.9 inches (W) x 16.8 inches (H) x 17.8 inches (D)
Weight 19.5 kg
43.0 lbs
Environmental Considerations
Operating Temperature: 10 ° C to +35 ° C
Humidity: 30% to 80%
Feet: 0 to 10,000 Feet
Storage Temperature: -20 ° C to +60 ° C
Humidity: 10% to 90%
Feet: 0 to 45,000 Feet
NOTE: Technical specifications are subject to change without notice.
