3. ASSEMBLY
The binoculars appearance is shown on the Figure 1. It
consists of the binocular itself, U-mount and tripod.
1. How to adjust the tripod
The tripod height can be adjusted by locknuts (1). Loosen
the locknuts (1) and pull out the legs (2) to get the desired
height, and then tighten the locknuts. The locknuts should
be reliably secured to mount the U bracket on the tripod.
2. How to mount the U bracket
Put the model U bracket on platform of the tripod (3), and
then fasten the locknut (4). The model U bracket must be
firmly fixed on the tripod.
5
3
7
U-bracket
