Installation

Page 3-5

NOTES:

• DIMM#2 & #3 shared same memory bus and DIMM#1 is dedicated for 2

nd

channel memory bus.
We recommend you to use DIMM socket of the same color to obtain the best
memory performance.
- For one DIMM memory configuration, the DIMM can be located on any of

DIMM#1 to DIMM#3 in 64-bit mode

- For two DIMMs memory configuration, the DIMMs should be located on

DIMM#2/#3 and DIMM#1 in 128-bit mode. It is preferable to use DRAM
DIMM of the same type and size.

- For three DIMMs memory configuration, the DIMMs can be located on all

DIMM sockets in 128-bit mode.

• Using non-compliant memory with higher bus speeds (overclocking) may

severely compromise the integrity of the system.

DDR DIMM 2

DDR DIMM 1

DDR DIMM 3

Bank 0

Bank 1

3-3 System Memory Configuration
Memory Layout
The mainboard accommodates three PC1600/2100/2700/3200 184-pin DIMMs (Dual In-
line Memory Modules):

• Supports up to 3.0GB of 200/266/333/400MHz DDR SDRAM

• Supports up to 3 DDR DIMMs (refer to Table 1)

• Supports 64/128/256/512Mb, 1Gb x8 & x16 DRAMs

• Supports

128

-bit

dual

channel memory architecture

• Supports unbuffered and non-ECC DIMMs

• Supports configurations defined in the JEDEC DDR DIMM specification

Figure 6 and Table 1 show several possible memory configurations.

1

DIMM

(64-bit)

2 DIMMs

(64-bit)

2 DIMMs

(128-bit)

3 DIMMs

(128-bit)

DIMM#1 SS/DS

SS/DS SS/DS

SS/DS

DIMM#2

SS/DS

SS/DS SS/DS

SS/DS

DIMM#3

SS/DS SS/DS

SS/DS

SS/DS
